Automatic Test Equipment for Freezing Point of Engine Coolant

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Standard：ASTM D1177, ASTM D2386
  • Power Supply：AC 220 V±10%, 50 Hz
  • Freezing Point Range：-54ºC~2ºC
  • Temperature of Cold Bath：-70ºC~20ºC

Base Info

  • Model NO.：AIC-2430
  • Heating Power：2kw
  • Display：Touch Screen
  • Dimension：560mm×550mm×810mm
  • Sample Stirring：0~120r,Min
  • Bath Liquid Stirring：1200r,Min
  • Application：Lubricating Oil Testing
  • Temp.Control Accuracy：±0.5ºC
  • Operation：Automatic
  • Test Sample：Engine Coolant and Condensation Liquids
  • Refrigeration Method：Imported Refrigerator Compressor
  • Language：English
  • Transport Package：Plywood Case
  • Specification：stainless steel
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：50 Sets,Month

Description

1Power supplyAC 220 V±10%, 50 Hz2Working bathstainless steel,double vacuum glass observing window3Freezing point range-54ºC~2ºC4Cold bath measurement temperature-70ºC~20ºC5Temperature controlling accuracy±0.5ºC6Bath liquids stirringelectric stirring.the power is 6W,1200r/min7Refrigerator systemimported refrigerator compressor8Sample stirringmechanical stirring is 0~120r/min,continuously adjustable9Ambient temperature≤30ºC10Relative humidity≤85%11Maximum power consumption2000W12Dimension560mm×550mm×810mm  Factory overviewAutomatic Test Equipment for Freezing Point of Engine Coolant
Customer Feedback

Germany
Automatic Test Equipment for Freezing Point of Engine Coolant
USA
Automatic Test Equipment for Freezing Point of Engine Coolant
Packae
Automatic Test Equipment for Freezing Point of Engine Coolant
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
