Ep Hipot Electric AC Hipot Tester 5kVA 50kv
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Strength Testing Machine
- Accuracy Grade：0.5
Base Info
- Model NO.：EPTC Series
- Display：Digital
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Display Meter：Can Be Designed as Needle or Digital Meter
- Testing Transformer：Oil,Gas,Dry Type at Option
- Input Voltage：AC 220V 110V 380V at Customized
- Voltage Degree：3kv5kv10kv15kv20kv30kv or More at Customized
- OEM：Support
- Test Voltage：Customized
- Capacity：Customized
- Leakage Current：Customized
- Box Type：5kVA or Below
- Table Type：10kVA or Above
- Cabinet Type：50kVA or Above
- Control Mode：PLC, Motorised, Manual at Option
- Protection Functions：Over-Current, Zero-Starting Sound Light Alarm
- Emergency Stop：Yes
- Language：All in English or Customized
- Transport Package：Plywood Case
- Specification：at customized
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：9030390000
- Production Capacity：2000,Year
Description
Oversize
m3(L×W×H)Voltage(v) Current(A) EPTC-M05 220 0.5 200 2.5 50/100 20×30×20 EPTC-M15 220 1.5 200 7.5 50/100 26×36×24 EPTC-M3 220 3 200 15 50/100 26×42×24 EPTC-M5 220 5 200 25 50/100 60×45×37 EPTC-M6 220 6 200 30 50/100 53×40×60 EPTC-M10 220 10 200 50/25 (50/100)/100 53×40×65 EPTC-M15 380 15 400 37.5 (50/100/150)/100 53×40×70 EPTC-M20 380 20 400 50 (50/100/150)/100 53×43×84 EPTC-M25 380 25 400 62.5 (50/100/150)/100 53×45×90 EPTC-M30 380 30 400 67.5 (50/100/150)/100 65×55×115 EPTC-M40 380 40 400 100 (50/100/150)/100 70×60×115 EPTC-M50 380 50 400 125 (50/100/150)/100 70×60×115
This series can be customized according the customer's requirements. More details on EPTC Series AC Hipot Tester please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
