ECE R118 Annex 8 Vertical Burning Rate and Flame Propagation Tester

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：12 Months
  • Connectors：USB
  • Test Mode：Saved Test
  • Usage：HDMI Cable Tester
  • Test Region：Forming Cable

Base Info

  • Model NO.：R1188
  • Cable Type：Shielded
  • Power：Electricity
  • Certification：CE
  • Color：White
  • Test Standard：ECE R118 Annex 8
  • Power Supply：220V 50Hz
  • Dimension of Cabinet：Length 1200mm X Width 600mmx Height 1300mm
  • Volume of Cabinet：0.55m³
  • Pressure Adjusting Range：0 ~ 0.4MPa
  • Burner Angle：0 to 45 Degrees
  • Display：LCD
  • Delivery Time：40 Days
  • Application：Cable and Wires Testing
  • Function：Determine The Vertical Burning Rate of Material
  • Burner Tube Length：100mm ± 10mm
  • Inner Diameter：9.5mm ± 0.3mm
  • Blue Flame Height：50mm ± 2mm
  • Total Flame Height：100mm
  • Language：English
  • Transport Package：Plywood Case
  • Specification：Stainless steel
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

1Burner angle0 to 45 degrees2Bunser burner sizeimported from the United States has a tube length of 100mm ± 10mm and an inner diameter of 9.5mm ± 0.3mm; it fully meets the requirements of the IEC60695-11-4 standard3Pressure regulating valve and pressure gauge0 ~ 0.4Mpa4Blue flame heightcontrol at 50mm ± 2mm; total height 100mm
Factory overview
ECE R118 Annex 8 Vertical Burning Rate and Flame Propagation Tester
Customer Feedback

Germany
ECE R118 Annex 8 Vertical Burning Rate and Flame Propagation Tester
USA
ECE R118 Annex 8 Vertical Burning Rate and Flame Propagation Tester
Package
ECE R118 Annex 8 Vertical Burning Rate and Flame Propagation Tester
FAQ
1.What's the delivery time?
About 40 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
