Soil Bench Triaxial Test Apparatus Device
Nanjing T-Bota Scietech Instruments & Equipment Co., Ltd.- After-sales Service：yes
- Warranty：one-year
- Type：Direct Shear
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Mechanical Load
Base Info
- Model NO.：TSZ30-2.0
- Loading Method：Dynamic Load
- Display：Needle
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：Under
- Place of Origin：Jiangsu, China (Mainland)
- Brand Name：Tbt
- Model Number：Tsz30-2.0
- Power：Electronic
- Usage：Triaxial Testing Apparatus
- Specimen：39.1 X 80mm, 61.8 X 125mm
- Capacity：3kn Maximum
- Strain Rate：0.0024 -4.5mm,Min. Low Rate
- Power Supply：220V ±10% 50Hz
- Transport Package：Standard Exporting Packing
- Specification：ISO9000
- Trademark：TBT
- Origin：Nanjing China
- HS Code：90158790
Description
I. Application:
TSZ30-2.0 Bench Triaxial Test Apparatus is used to determine the strength and deformation characteristics of the soil specimen under the static axial load. It can perform unconsolidated-undrained shear test (UU), consolidated-undrained shear test (CU) and consolidated-drained shear test (CD). With high confining pressure, it does not need air-compressor and nitrogen cylinder. It can meet test requirements for civil engineering projects such as large buildings and dam construction etc.Product Parameters
II. Specification:Business Fields
Packaging
Clients Feedbacks
FAQ
1. How long is the delivery time?
Normally goods will be shipped out within 7-10days after contract signed and down payment received.
2. Is it possible to make our own brand/logo on your product?
Yes, but depends on MOQ.
3. What's your MOQ?
This depends on different types of products. If it is a large machine, the MOQ is usually 1 set. For small instruments, such as thermometers, the MOQ is 50 pieces.
4. What kind of payment term you accept?
Normally,
1) If total contract value less than USD 10,000.00 : 100% T/T in advance after contract signed.
2) If total contract value more than USD 10000.00 : 50% T/T in advance after contract signed and 50% T/T after receipt of BL copy. Or, irrevocable LC is acceptable.
