• Model NO.：ZC-210-010
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：35.7kg
• Power Source：220V
• Oil Cylinder Position：None
• Voltage Withstands Time：1-10 Minutes
• Warranty：1 Year
• Single Package Size：49X35X40cm
• Transport Package：Wooden Box
• Specification：420mm*380*mm410mm
• Trademark：KvTester
• Origin：China
• HS Code：9031809090
• Production Capacity：500,Month

Input voltage

AC 220V

Output voltage

AC 0~80KV/100kv

 Voltage boosting speed

2KV/S ±10%

Accuracy degree

3

Number of times of continuous test

1-9

Stirring time

0~99 seconds

Standing time

0-9 minutes 59 seconds

Can store 100 groups data.

Voltage limit setting

20KV-70KV

Voltage withstands time

1-10 minutes

Temperature

5-40ºC

Dimension

420mm ×380mm ×410mm

Weight

28kg

Accessory List

No.

Device name

Number

1

The equipment

1

2

The oil cup

1

3

The power cord

1

4

Standard gauge

1

5

Insurance tube

2(3A)

6

Impeller

2

7

Tweezers

1

8

Ground wire

1

9

Printing paper

1
