ASTM D323 Rvp Test Apparatus for Vapor Pressure of Petroleum Products (Reid Method)

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Standard：ASTM D323, ISO3007, Nfm07007
  • Test Method：Reid Method
  • Temperature Control Range：(Room Temp.~90)ºC
  • Power Supply：AC(220±10%)V, 50Hz

Base Info

  • Model NO.：VPT-M
  • Working Unit：2
  • Total Power Consumption：1700W
  • Display：LCD
  • Temperature Accuracy：0.1ºC
  • Accuracy of Pressure Meter：0.4%F·s
  • Application：Gasoline, Volatile Crude Oil etc
  • Dimension：350mm×340mm×750mm
  • Color：White
  • Function：Determine Vapor Pressure of Gasoline and Crude Oil
  • Transport Package：Plywood Case
  • Specification：Stainless steel
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

Basic Info.

Model NO. VPT-M Working Unit 2 Total Power Consumption 1700W Display LCD Temperature Accuracy 0.1ºC Accuracy of Pressure Meter 0.4%F·s Application Gasoline, Volatile Crude Oil etc Dimension 350mm×340mm×750mm Color White Function Determine Vapor Pressure of Gasoline and Crude Oil Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 20 Sets/Month

Product Description

Summary
   This  Rvp Test Apparatus is made and designed as per national standard of People's Republic of China GB/T 8017 Petroleum Products- Determination of vapor pressure- Reid method. It is used to test make determination for vapor pressure of gasoline, volatile crude oil and other volatile petroleum products.

I. Main technical features
1. Digital temperature controller. The temperature in water bath is uniform. Temperature control accuracy is high. It can meet the requirements of test.
2. The  Rvp Test Apparatus has two precise pressure meters to detect the gas pressure inside the bomb.
3. Two sets of vapor pressure bombs. It can do synchronous tests.

II. Main technical specifications
1. Power supply:   AC(220±10%)V, 50Hz
2. Total Power consumption:  ≤ 1700W
3. Temperature control range of bath:  (Room temp.~90)ºC
4. Temperature control accuracy of bath: ±0.1ºC
5. Accuracy of pressure meter:  0.4%F·S
6. Ambient temperature: (15~35)ºC
 Relative humidity: ≤85%
7. Dimension: 350mm×340mm×750mm
Factory overview
ASTM D323 Rvp Test Apparatus for Vapor Pressure of Petroleum Products (Reid Method)
Customer Feedback

Germany
ASTM D323 Rvp Test Apparatus for Vapor Pressure of Petroleum Products (Reid Method)
USA
ASTM D323 Rvp Test Apparatus for Vapor Pressure of Petroleum Products (Reid Method)
Package
ASTM D323 Rvp Test Apparatus for Vapor Pressure of Petroleum Products (Reid Method)
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
