Large Photosensitive Area Accurate Measurement Portable Grating Spectrophotometer
Beijing Samyon Instruments Co., Ltd.- After-sales Service：24hrs
- Warranty：1 Year
- Product Name：Grating Spectrophotometer
- Model：Flat Grating
- Wavelength Range：400~700nm
- Wavelength Interval：10nm
Base Info
- Model NO.：SY7700
- Semiband Width：10nm
- Reflectance Range：0-200%
- Observer Angle：2-10 Degree
- Transport Package：Carton
- Specification：SY268
- Trademark：SAMYON
- Origin：Cn
- HS Code：9031809090
- Production Capacity：999 Per Week
Description
RepeatabilitySpectral reflectance: MAV/SCI, Standard deviation within 0.08% (400 nm to 700 nm: within 0.18%) Chromaticity value: MAV/SCI, within ΔE*ab 0.02 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration) Inter-instrument Error MAV/SCI, Within ΔE*ab 0.15
(Average for 12 BCRA Series II color tiles) Measurement Mode Single Measurement, Average Measurement(2-99times) Locating Method Camera Locating,stabilizer cross position Dimension L*W*H=129X76X217mm Weight Approx 600g Battery 3.7V,5000mAh Li-ion battery, 6000 measurements within 8 hours Illuminant Life Span 5 years, more than 3 million times measurements Displayed Data 3.5-inch TFT color LCD, Capacitive Touch Screen Data Port USB, Bluetooth 4.2 Data Storage Standard 1000 Pcs, Sample 30000 Pcs Language Simplified Chinese, English, traditional Chinese Operating Environment 0~40ºC, 0~85%RH (no condensing), Altitude < 2000m Storage Environment -20~50ºC, 0~85%RH (no condensing) Standard Accessory Power Adapter, User Guide, PC Software(Download from office website), USB cable, White and Black Calibration Cavity, Protective Cover, Wrist strap, 8mm flat aperture, 8mm tip aperture, 4mm flat aperture, 4mm tip aperture Optional Accessory Micro Printer, Powder Test Box Notes The specifications are subject to change without notice.
