• Model NO.：YWT-IPX3
• Thiickness of Staninless Steel Plate：1.2mm
• Accessories：Wiper, Casters with Adjusters, etc
• Test Time：30mins
• Application：Light,Lamp, Auto Parts, Electronics, etc.
• Transport Package：Good Package
• Specification：CE, ISO SGS certified.
• Trademark：Yuanyao
• Origin：China
• HS Code：9032100000
• Production Capacity：5 Sets,Month

Major Specifications:ModelYSRT-1728-AYSRT-1728-E(IEC-529)(CNS14165) Internal Dim.WHD(mm)1200×1200×12001200×1200×1200 External Dim.WHD(mm)1750×1850×13001750×1850×1300 Water Temp.NormalNormal
Spray Type
Total water
 flow(L/min)R11.8IP×1With in 1--1.5mm/min(In drip box)R23.2IP×2With in 3--3.5mm/min(In drip box)S124.5IP×3angle±600,R:400mm,1.1L/minS239.2IP×4angle±1800,R:400mm,1.8L/min
Preesure of
spray nozzle
(kgf/cm 2 )R10.11.Flow rate of the water=0.07L/min
2.IP×3,Radius:400mm,Number or open holes=16,total water flow:1:1L/min.
3.IP×4,Radius:400mm,Number or open holes=25,total water flow:1:8L/min.
*Radius:200mm,R400mm.(For IP×3,IPx4)R20.3S11S23(RPM)Test Specimen Frame17RPM1RPM
   Spray Nozzle Rotation Speed23RPM
Swing 60°from vertical for 4 seconds at one time

Swing 180°from vertical for 12 seconds at one time
   Material InteriorSUS#304 Exterior Other ComponentsChamber lamp.Wiper
casters with AdjustersChamber lamp.Wiper,casters with Adjusters Power Source [K.W]AC 1Ψ 220V 60/50Hz 4KW

In addition to IEC60529 IPX1 ~ IPX6 grade water rain spray test chamber, we are also manufacturing:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.

Other styles / size with different configurations are available upon request, welcome to enquire and purchase!
