• Model NO.：YWER-8000
• Power Source：AC220V
• Oil Cylinder Position：Under
• Inner Chamber Size(W*H*D)：Can Custom
• Temperature Range：0-80c
• Temperature Fluctuation：+,-0.3c
• Power Supply：AC 220V 50Hz,AC 3 Phase 380V 60,50Hz
• Transport Package：Good Package
• Specification：CE, ISO SGS certified.
• Trademark：Yuanyao
• Origin：China
• HS Code：9032100000
• Production Capacity：5 Sets,Month

ModelYWERInternal Dim.W×H×D(mm)Please refer to size chartExternal Dim.W×H×D(mm)Temp. Range0°C;-20°C;-40°C;-60°C~+70°C(+80°C)Relatice Humidity Range30~90%RH±0.3°C;PerformanceTemp.&Humi.Constancy±0.3°C;±2.5%RHTemp.&Humi.Uniformity±0.1°C;±5%RHIndication Resolution0.1°C; 0.1%RH/0.01; 0.1%RHHeat-up Time°C80min50Pull-down Time°C0-20-40min5570100MaterialExteriorSUS#304 Stainless steel/PVC+Powder CoatedInteriorSUS#304 stainless steel piateInsulationPloyurethane foam 100mm (75mm) (50mm)SystemsCirculationSiroco fanHeatingSUS#304 stainless steel high-speed heaterHumidifyingSurface evaporating systemCoolingAirtight compressor+vaporator fins+air-cooling
(or water-cooling)condenserDehumidifyingADP Critical dewpoint cooling/dehumidifying methodControllerDigital electronic indicators+S.S.R.With PIDOther ComponentsAirtight compressor+evaporator fins+air-cooling
(or water-cooling)condenserSafety DevicesOverheating prevention ciruit-breaker, compressor overload protection,control system overload,humidifying system
overheating & drying out prevention, breakdown indicator light.Power Source(K.W)AC 1Ψ 220V 50Hz; 3Ψ 380V 60/50Hz











Yuanyao company profile:

Since 2004 we went into the environmental test chambers industry. In 2005 we eastablished our own

factory-Dongguan Yuanyao Electronics Technology Co., Ltd, which has become an important

manufacturer of environmental friendly test chambers.

Our main products include

Temperature humidity chambers

Thermal shock chambers

Walk-n stability chambers

LCM(LCD) aging chambers

Hot ovens

Vacuum ovens

Hot air clean dryers

Salt spray testers

Steam aging testers

Dust resistance chambers

Water test chambers

UV/Xenon aging test chambers

Glue dispensing machines

Ozone test machines

High altitude low pressure simulation test chambers

Air ventilation aging test chambers

Fast chamber rate cliamte chambers (ESS chamber)

Combined temp. humidity & vibration test chambers and so on...

If you want to know more, please feel free to contact us, thanks!
