ASTM D611 Petroleum Products Aniline Point Tester
Chongqing Advanced Technology Co., Ltd.- After-sales Service:Response in 12 Hours
- Warranty:1 Year
- Test Standard:ASTM D611,ISO 2977
- Heating Mode:Electric Heating Tube
- Stirring Method:Soft Shaft Mixing
- Detection Method:Photoelectric Detection
Base Info
- Model NO.:APT-M
- Measuring Range:Room Temperature ~ 150ºC
- Function:Determination of Aniline Point of Petroleum Produc
- Temperature Adjustment:Solid State Regulator
- Operation:Manual
- Power Supply:AC220V 50Hz
- Application:Oil Testing
- Color:White
- Price:Low
- Delivery Time:20 Days
- Transport Package:Plywood Case
- Specification:Vertical type
- Trademark:AI
- Origin:China
- HS Code:9031809090
- Production Capacity:20 Sets,Month
Description
Basic Info.
Model NO. APT-M Measuring Range Room Temperature ~ 150ºC Function Determination of Aniline Point of Petroleum Produc Temperature Adjustment Solid State Regulator Operation Manual Power Supply AC220V 50Hz Application Oil Testing Color White Price Low Delivery Time 20 Days Transport Package Plywood Case Specification Vertical type Trademark AI Origin China HS Code 9031809090 Production Capacity 20 Sets/MonthProduct Description
IntroductionThis Aniline Point Tester is suitable for the determination of aniline point of petroleum products by placing a specified volume of aniline and sample in a test tube and mixing it with mechanical agitation. The mixture is heated at a controlled rate until the two phases are completely mixed. The mixture is then cooled at a controlled rate, and when the two phases are separated, the recorded temperature is the aniline point.
Main features
1,The result of photoelectric detection and separation is accurate;
2,The Aniline Point Tester uses high-power solid-state voltage regulator controls the heating rate;
3,The voltage device displays the temperature rise state;
4,Integrated structure is easy to operate;
5,Standard glass test tubes of Aniline Point Tester comply with standard requirements;
Specifications
1, Applicable standards: ISO2977,GB/T262,ASTM D611
2, Heating method: electric heating tube heating
3, Mixing method: soft shaft mixing
4, Detection method: photoelectric detection
5, The measurement range: room temperature ~ 150ºC
6, Working power: AC220V 50HZ
7, Temperature adjustment: solid state regulator
Packing list of Aniline Point Tester
No. | Name | Quantity |
1 | Main unit | 1 Set |
2 | Glass tube | 1 PC |
3 | Thermometer(25~105ºC,0.2ºC) | 1 PC |
4 | Thermometer(90~170ºC,0.2ºC) | 1 PC |
5 | Fuse | 4 PCS |
6 | Manual book | 1 Copy |
Factory overview
Customer Feedback
Germany
USA
Package
FAQ
1.What's the delivery time?
About 20 days.
2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.
3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.
4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
