SPECIFICATIONS |
| TFG3908A | TFG3912A | TFG3916A |
Frequency |
Range
| Sine | 1μHz ~ 80MHz | 1μHz ~ 120MHz | 1μHz ~ 160MHz |
Square, Pulse | 1μHz ~ 30MHz | 1μHz ~ 40MHz | 1μHz ~ 50MHz |
Arbitrary | 1μHz ~ 30MHz |
Ramp | 1μHz ~ 5MHz |
Resolution | 1μHz |
Accuracy | ±(2ppm+1μHz) |
Waveform |
Type | 150 kinds, including sine, square, ramp, pulse, noise,PRBS,Exponential,Logarithm,Tangent,Gausiian,Cardiac,Quake,etc. |
Length | 16384 points |
Sample Rate | 500MSa/s |
Vertical Resolution | 14bits |
Amplitude |
Range
| Frequency≤40MHz | 1mVpp~10Vpp (50Ω load) |
Frequency≤80MHz | 1mVpp~5Vpp (50Ω load) |
Frequency≤120MHz | 1mVpp~2.5Vpp (50Ω load) |
Frequency>120MHz | 1mVpp~2Vpp (50Ω load) |
Accuracy | ±(1% of setting+2mVpp) |
Flatness (sine, relative to 1MHz) | ±0.2dBm, frequency<80MHz |
±0.3dBm,frequency≥80MHz |
Offset |
Range | ±10Vpk (ac+dc, open circuit) ±5Vpk (50Ω load) |
Accuracy | ±(1% of setting+2mV+0.5% of amplitude) |
Modulation |
FM, AM, PM, PWM, Sum Modulation
| Modulation Frequency | 1mHz ~ 100kHz (FM, AM, PM,PWM) 1mHz~1MHz(Sum) |
AM Modulating Depth | 0% ~ 120% |
Phase Deviation | 0° ~ 360° |
Pulse Width Deviation | 0% ~ 99% |
Sum Amplitude | 0% ~ 100% |
Source | internal, external |
FSK, 4FSK,QFSK,PSK 4PSK,QPSK,ASK,OSK | Hope Frequency | 1μHz ~ maximum frequency |
Rate | 1mHz ~ 1MHz |
Source | internal, external |
Sweep |
Waveform | Sine,Square,Ramp,etc. |
Type | Linear,Log,List |
Sweep Time | 1ms ~ 500s |
Return/Hold/Interval Time | 0s ~ 500s |
Trigger Source | Internal,External or Manual |
Burst |
Waveform | sine, square, Ramp,etc |
Period | 1μs ~ 500s |
Burst Count | 1 ~ 100000000 |
Start/End Phase | 0° ~ 360° |
Trigger Source | internal, external, manual |
Channel Coupling |
Frequency Coupling | Frequency Ratio, Frequency Difference |
Ampliitude Offset Coupling | Amplitude Difference, Offset Difference |
Waveform Coupling | Comination Amplitude, 0% ~ 100% |
SYNC Output |
Level | TTL compatible, edge time≤10nS |
Impedance | 50Ω (typical) |
Counter |
Frequency Range | 0.01Hz ~ 350MHz Resolution: 7 digits/s |
Period, Pulse Width Measurement | 100ns ~ 20s |
Duty Cycle Measurement | 0.1% ~ 99.9% |
General Characteristics |
Power | AC 100 ~ 240V, 45 ~ 65Hz, <30VA |
Dimension & Weight | 367×256×106 mm, Approx.3.7 kg |
