• Model NO.：TFG6910A,6920A,6930A,6940A,6960A
• Counter Frequency：Max 350MHz
• OEM/ODM：Yes
• Interface：USB Host & Device, RS-232
• Modulation：FM, Am, Pm, PWM, Sum, Fsk, Bpsk
• Sweep Time：5ms~500s
• Burst Count：1~1000000
• Sweep Type：Linear, Log
• Transport Package：Carton
• Specification：334*256*106 mm
• Trademark：SUIN
• Origin：China
• HS Code：854320909
• Production Capacity：30, 000 Sets,Year

 TFG6910ATFG6920ATFG6930ATFG6940ATFG6960AFrequency RangeSine1μHz ~ 10MHz1μHz ~ 20MHz1μHz ~ 30MHz1μHz ~ 40MHz1μHz ~ 60MHzSquare, Pulse1μHz ~ 10MHzothers1μHz ~ 5MHzResolution1μHzAccuracy±(50ppm+1μHz)WaveformTypeSine, Square, Ramp, Pulse, Noise, 50 built-in waveforms + 5 user-defined waveformsLength4096 pointsSample Rate120MSa/s150MSa/sVertical Resolution14 bits(CHA); 10 bits(CHB)Amplitude CharacteristicsRangeFrequency≤20MHz0.1mVpp to 10Vpp(50Ω)  0.2mVpp to 20Vpp(Open circuit)Frequency>20MHz0.1mVpp to 7.5Vpp(50Ω)  0.2mVpp to 15Vpp(Open circuit)Resolution1mVpp (Amplitude≥1Vpp, load 50Ω)                    0.1mVpp(Amplitude<1Vpp, load 50Ω)2mVpp (Amplitude≥2Vpp, open circuit)                 0.2mVpp(Amplitude<2Vpp, open circuit)Accuracy±(1% of setting+1mVpp)(1kHz Sine, 0V offset, auto range)Offset CharacteristicsRange±5Vdc (50Ω), ±10Vdc (open circuit)Accuracy±(1% of setting+1mVdc)Modulation Characteristics (CHA)FM,AM,PM,PWM,SUMCarrier Waveform: Sine, Square, Ramp, etc. (only Pulse for PWM)Modulating Waveform: Sine, Square, Ramp, etc.FSK,BPSKCarrier WaveformModulating Frequency: 1μHz ~ 100kHzSine, Square, Ramp, etc.SourceInternal/ExternalSweep Characteristics (CHA)Carrier   WaveformSine, Square, Ramp, etc.TypeLinear or LogarithmicSweep Time5ms~500sHold/Return Time0s~500sTrigger SourceInternal, External and ManualList SweepList Length: 600 pcsBurst Characteristics (CHA)Carrier   WaveformSine, Square, Ramp, etc.Burst Count1 ~ 1000000Period1μs ~ 500sTrigger   SourceInternal, External, ManualCounterFrequency   Range 10mHz ~ 350MHz, resolution: 6 digits/sPeriod,   Pulse Width100ns ~ 20sDuty Cycle1% ~ 99%General   CharacteristicsPowerAC 100 ~ 240V, 45 ~ 65Hz, < 30VADimension   & Weight334×256×106 mm, Approx.3 kg
Standard Accessories:
Power Cord*1
BNC cable*1
CD(Software +User's Guide)*1

Options:
Power Amplifier     Power:8W(load 8Ω)
TCXO                    Frquency Stability:±2ppm
