Transformer Oil Test Equipment Breakdown Voltage Tester
Kvtester Electronics Technology Co., Ltd.- Max Diameter of Workpiece：>3200mm
- Mass Scope of Workpiece：35.7kg
- Type：Universal Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Electronic Load
Base Info
- Model NO.：ZC-210-018
- Loading Method：Static Load
- Display：Digital
- Control：Manual Control
- Weight：35.7kg
- Power Source：220V
- Oil Cylinder Position：None
- Voltage Withstands Time：1-10 Minutes
- Warranty：1 Year
- Single Package Size：49X35X40cm
- Transport Package：Wooden Box
- Specification：420mm*380*mm410mm
- Trademark：KvTester
- Origin：China
- HS Code：9031809090
- Production Capacity：500,Month
Description
Input voltage
AC 220V
Output voltage
AC 0~80KV/100kv
Voltage boosting speed
2KV/S ±10%
Accuracy degree
3
Number of times of continuous test
1-9
Stirring time
0~99 seconds
Standing time
0-9 minutes 59 seconds
Can store 100 groups data.
Voltage limit setting
20KV-70KV
Voltage withstands time
1-10 minutes
Temperature
5-40ºC
Dimension
420mm ×380mm ×410mm
Weight
28kg
Accessory List
No.
Device name
Number
1
The equipment
1
2
The oil cup
1
3
The power cord
1
4
Standard gauge
1
5
Insurance tube
2(3A)
6
Impeller
2
7
Tweezers
1
8
Ground wire
1
9
Printing paper
1
