• Model NO.：AIC-5182
• Motor Power：6.5,8kw
• Motor Speed：1450,2880 R,Min
• Gear Box Volume：1.25L
• Heating Power：0.5X3=1.5kw
• Power Supply：AC220V±10V 50Hz
• Dimension：1390X750X1082mm
• Loading Mode：Rod Hanging Weights
• Fluction Range：±10%
• Function：Evaluate The Scuffing Load Capacity of Oils
• Display：LCD
• Color：White and Red
• Transport Package：Plywood Case
• Specification：Small
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：50 Sets,Month

Max. torque

1Kn. m

Max. loading class

Temperature control accuracy

±2ºC

Motor power

6.5/8kw

Motor speed

1450/2880 r/min

Gear box volume

1.25L

Heating power

0.5X3=1.5kw

Dimensions

1390X750X1082mm

Working conditions

1.The fluctuation range of the power supply voltage should not exceed the rated value ± 10% and the fluctuation range of the frequency should not exceed 2% of the rated value.
2.Test FZG test equipment should be installed horizontally and the installed base should be smoothly. The horizontal error for the host workbench aspect direction should not exceed 0.2/1000.
3.Room temperature 10 º C-35 º C.
4.The environment no vibration, no strong magnetic interference and non-corrosive media.
5>Relative humidity less than 80%.

Structural characteristics and working principle
1. Loading mode
This FZG scuffing loading capacity test equipment is a dynamic closed-loop configuration, and load mode adopts rod hanging weights mode.
The loading lever is hung on the load sheave clutch. By hanging weights plus through fastening loaded clutch nut and make the two sheave tighten which installed on the loaded clutch. Then remove the weights and the loading lever and you can readout the torque on the clutch torque measurement.

2. Installation and adjustment
Make the FZG test machine at the level of the floor and mat three horns. Put the spirit level on the test table. By adjusting the horn to make the vertical and horizontal direction error do not exceed 0.2/1000.
The fzg test machine host should be placed separately from the control cabinet to avoid the noise and pungent odor when the testing machine working. After the start of the FZG test machine, person can not inter into the room which the machine placed.
The test procedure in accordance with the the "lubricant carrying capacity assay (CL-100 gear machine method) SH/T0306-92" provisions.
