Wire and Cable Sprk Detection Machine, Frequency AC Spark Tester

Alpha Technical Industrial Co., Ltd.
  • After-sales Service：Available
  • Warranty：One Year
  • Connectors：RJ45
  • Test Mode：Instant Test
  • Usage：Network Cable Tester, HDMI Cable Tester, Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester
  • Test Region：Forming Cable

Base Info

  • Model NO.：ALPHA
  • Cable Type：Shielded
  • Power：Electricity
  • Certification：CE, RoHS
  • Customized：Customized
  • Product Name：Cable AC Spark Tester
  • Model：St-25at
  • Voltage Output：2.0-25kv
  • Detection Speed, Max：350m,Min
  • Detected Wire Outside Diameter：Max100mm
  • Dectection Resolution：0.05s
  • Transport Package：Wooden Cases
  • Specification：Customized
  • Trademark：Alpha
  • Origin：China Jiangsu
  • HS Code：8456301090
  • Production Capacity：5000set,Year

Description

Complying with the requirements of GB3048.9-1994 and JB/T 4728.10Dectection resolution0.05s0.05s0.05sTransient breakdown current100mA50mA50mASteady short-circuit current<20mA<20mA<20mADetction Speed, Max300m/min350m/min350m/minOverall diameter of tested wire or cable, max≤30mm≤55mm≤100mmWire and Cable Sprk Detection Machine, Frequency AC Spark TesterWelcome to inquiry!
