• Model NO.：ND-STA-856F
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：None
• Tester Max Dimension：850X950X1870
• Control Method：Computer
• Working Station：2
• Dielectric Strength Test Condition：AC 0-3000V Adjustable
• Certificate：CCC
• Insulation Resistance Test Condition：DC 500V
• Machine Weight：250kg
• Color：Ral9010 or as Per Customer Requirement
• Transport Package：1 Ply-Wooden Case
• Specification：customized
• Trademark：NIDE
• Origin：China
• HS Code：9030390000
• Production Capacity：200 Sets,Year

output voltage setting range/precisionAC 500~3000V±(2%×setting value+10V)breakdown current testing range/precision0.10~20.00mA±(2%×display value+0.05mA)Hipot current presetting alarm rangeMax: 0.10~20.00mA; Min: 0.00~20.00mAHipot current/resolution±(2%×display value+0.05 mA);0.01 mAtest time range/resolution0.5~999.9s 0.1s/steparc detection0~9 grade

2. Insulation Resistance:apply DC high voltage between winding and iron core and check the insulation resistance of testing loop.

output voltage setting range/precisionDC 500V/1000V ±(2%×setting value+10V)insulation resistance testing range/precision

1~500MΩ

≤100MΩ:±(3%×setting value+0.5MΩ) ;>100 MΩ:±(5%×setting value+5MΩ)

insulation resistance alarm setting rangeMax: 0~500MΩ; Min: 1~100MΩtest time range/resolution0.5~999s 0.1s/step

3. Surge:apply impulse high voltage to windings, and compare the oscillation graph with the saved graph.

output voltage setting range/precision500~3000V ±(3%×setting value+10V)sampling frequency100MHzwaveform comparison

area, area difference, corona and phase

3 waveforms displayed in the testing interface

4. DC winding resistance:four-wire resistance measuring method. Apply DC current to the windings and test the temperature and winding resistance under current environment. The resistance will be converted to the value under designated temperature(generally 20ºC or 25ºC) automatically.

testing range and precision10.0mΩ~20KΩ±(0.3%×display value+3 words) temperature compensation can be set.test time range/resolution0.5~999s 0.1s/stepresolution0.001 ohmtemperature probe/rangeDS18b20 -10.0ºC~+50.0ºCprecision±0.5°C(range: -10ºC~+50ºC)

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
