Single Cable Vertical Burning Test Equipment
Shenzhen Bonad Instrument Co., Ltd.- Connectors:Ethernet Cat 5
- Test Mode:Vertiacl Test
- Usage:Network Cable Tester, Digital Cable Tester
- Test Region:Forming Cable
- Cable Type:Electric Wire
- Power:Electricity
Base Info
- Model NO.:BND-DDR
- Certification:CE
- Customized:Customized
- Color:Orange
- Ignition Time:0-999.9, Adjustable
- Burning Time:0-999.9s, Auto Record, Manual Stop
- Gas:98%Propane
- Transport Package:Wooden Box
- Specification:300*450*1200
- Trademark:BND
- Origin:Guangdong Shenzhen
- Production Capacity:100 Sets Per Month
Description
Basic Info.
Model NO. BND-DDR Certification CE Customized Customized Color Orange Ignition Time 0-999.9, Adjustable Burning Time 0-999.9s, Auto Record, Manual Stop Gas 98%Propane Transport Package Wooden Box Specification 300*450*1200 Trademark BND Origin Guangdong Shenzhen Production Capacity 100 Sets Per MonthProduct Description
Single cable vertical burning test equipmentTest standard:
This vertical burning test instrument is conformance to IEC60332 and several standards, it use specified size Bunsen burner and propane, vertical burn the sample at certain height and angle, according to the ignition time, burning time and burning length to determine whether the sample has danger on fire.
Application:
It is mainly for accessing the flammability of single cable which conductor's diameter is bigger than 8mm (sectional area bigger than 0.5mm2) or smaller than (sectional area smaller than 0.5mm2) . It is applied to lighting equipment, low-voltage apparatus, household appliances, electric tool, electro-technical instruments and parts for researching, manufacturing and quality inspection.
Product picture:
Technical Parameters:
Burner | 1pcs Inner diameter 2mm ± 0.5mm and 1pcs inner diameter 9.5mm ± 0.5mm Busun Burner |
Test angle | 45° |
Burn height | 20mm ± 2mm to 190mm±1mm adjustable |
Ignition time | 0-999.9s±0.1s adjustable |
Burning time | 0-999.9s±0.1s,auto record, manual stop |
Gas | 98% propane (can be replaced by liquefied petroleum gas in normal case) |
Flow pressure | Double-range recording meter and pressure gauge(gas and air) |
Outer size | 385x204x360 mm |
Temperature range | 0~1000ºC |
Fire temperature requirement | From 100ºC±5ºC rise to 700ºC±3ºC in 45sec±2sec |
Thermometer | Φ0.5mm(K type) |
Process | Auto test, no individual ventilation |
Standard | IEC60332-1 |
Chamber dimension | 0.15 m3 , exclude door |
Instrument dimension | 550x450x1380(mm) |
Power supply | AC220V,50Hz,≤500W |
