• Model NO.：YSA-5
• Temp.Reslution：±0.1ºC
• Heating-up Time：30min
• Exterior Chamber Material：Cold Rolled Plate + Powder Coating
• Insulation Material：PU & Fibergalss Wool
• Heating System：SUS#Stainless Steel High-Speed Heater
• Transport Package：Standard Export Strong Wooden Case
• Specification：CE, ISO, SGS, TUV certified.
• Trademark：Yuanyao
• Origin：China
• HS Code：9101199000
• Production Capacity：100 Sets,Month

ModelYSA-4YSA-5Test basket.W×H×D(mm)100×54×260,3Sets100×54×260,4SetsExternal Dim.W×H×D(mm)610×540×340760×540×340PerformanceTemp.RangeR.T+10°C ~ +98°CTemp.Constancy±0.3°CTemp.Resolution±0.1°CHeat-up(min)45MaterialExteriorSUS#304 stainless steel piateInteriorSUS#304 stainless steel piateInsulationPU & Fiberglass woolSystemsHeatingChrome Steel Strip Wire HeaterControllerDigital electronic indicators controller+S.S.R.With P.I.D & timer max 9,990minsSafety DevicesOverheating prevention pretector,
Water shortage protector, steam outlet hole, no fuse breakerPower Source(K.W.)AC 1Ψ 220V 60/50Hz1.12.5
