• Model NO.：ZXDN-3561
• Display screen：5.7-inch 640*480 color
• Memory capacity：128M bit FLASH
• External storage interface：USB (U disk can be plugged in)
• Working power supply：Lithium battery,working for 5 ~ 6 hours
• External power supply：AC100 ~ 240V , DC16.8V-1A power adapter , charger
• Transport Package：Wooden Case or Carton
• Specification：Universal Testing Machine
• Trademark：GDZX
• Origin：China
• Production Capacity：1200sets,Year

Harmonic

measurement

1. Voltage signal input circuit:

      Direct access

      Input impedance: 1MΩ, 20pF

      Measuring range: voltage true effective value 700V (effective value)

      Power consumption: less than 0.5VA / phase

2. Current input circuit:

      Indirect access

      Measuring range: current true effective value 1A, 5A, 10A, 100A, 500A, 1000A, 3000A (select corresponding current sensor)

      Power consumption: less than 0.5VA / phase

3. Frequency range of measurement signal: 40Hz ~ 70Hz

4. Display screen: 5.7-inch 640 × 480 color graphic LCD + touch screen

5. Memory capacity: 128M bit FLASH

6. External storage interface: USB (U disk can be plugged in)

7. Working power supply: rechargeable lithium battery, full charge, working for 5 ~ 6 hours

8. External power supply: AC100 ~ 240V / DC16.8V-1A power adapter / charger

Features

1. Voltage, current, frequency: can measure three-phase voltage, zero-line voltage, three-phase current, zero-line current, frequency, etc.

2. Harmonic measurement: can measure up to the 50th harmonic, and the measurement results include the amplitude of each harmonic voltage, the amplitude of the harmonic current, the total distortion of the voltage harmonics (total distortion rate), and the harmonic / current of each voltage Harmonic content rate; can display harmonic spectrum.

3. Power measurement: It can measure three-phase apparent power, active power, reactive power, power factor, three-phase energy, etc.

4. Three-phase unbalance measurement: can measure three-phase voltage unbalance and positive sequence, negative sequence, zero sequence voltage; three-phase current unbalance and positive sequence, negative sequence, zero sequence current, can display voltage vector, Current vector illustration.

5. Inrush current: At least 40 inrush current events can be recorded.

6. Fluctuation / flicker: Fluctuation, short-term flicker, and long-term flicker measurement.

7. Swell / Swell: Can record voltage swell and sag events, can record up to 40 events.

8. Monitoring record: The basic (steady state) power quality parameters can be recorded for a long time, and the recording time interval can be adjusted from 3 seconds to 30 minutes.

9. Digital oscilloscope: can be used to view the voltage / current signal waveform.
