ASTM D36 Automatic Softening Point Tester by Ring and Ball Apparatus

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Standard：ASTM D36
  • Power Supply：AC(220±10%)V, 50Hz
  • Measurement Range：5ºC~160ºC
  • Temperature Resolution：0.1 ºC

Base Info

  • Model NO.：SPT-I
  • Heating Rate：(5.0±0.5) ºC, Min
  • Heating Power：600W
  • Beaker Volume：800ml
  • Total Power Consumption：≤ 850 W
  • Dimension：270mm×200mm×330mm(L*W*H)
  • Weight：3kg
  • Test Position：2 Units
  • Display：LCD
  • Test Method：Ring and Ball Apparatus
  • Application：Asphalt and Bitumen Testing
  • Function：Determine Softening Point of Petroleum Asphalt
  • Transport Package：Plywood Case
  • Specification：Automatic
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

1Power supplyAC(220V±10%)V, 50 Hz2Measurement range(1) Heating medium: 5 ºC~80 ºC distilled water(softening point ≤80 ºC)
(2) Heating medium: 32 ºC~160 ºC glycerin (softening point > 80 ºC)3Temperature resolution0.1 ºC4Heating rateit will be adjusted to (5.0±0.5) ºC/ min automatically after three minutes5StirrerStirring speed can be adjusted continuously6Heating power600 W7Beaker volume800ml8Working conditionEnvironmental temperature:15ºC~35ºC;
Relative humidity: ≤ 85%9Total power consumption≤ 850 W10Dimension270mm×200mm×330mm(L*W*H)11Net weight3KG





Factory overviewASTM D36 Automatic Softening Point Tester by Ring and Ball Apparatus
Customer Feedback

Germany
ASTM D36 Automatic Softening Point Tester by Ring and Ball Apparatus
USA
ASTM D36 Automatic Softening Point Tester by Ring and Ball Apparatus
Package
ASTM D36 Automatic Softening Point Tester by Ring and Ball Apparatus
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
