Automatic Ring and Ball Test Instrument for Softening Point of Bitumen by ASTM D36

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Standard：ASTM D36
  • Power Supply：AC(220±10%)V, 50Hz
  • Measurement Range：5ºC~160ºC
  • Temperature Resolution：0.1 ºC

Base Info

  • Model NO.：SPT-II
  • Heating Rate：(5.0±0.5) ºC, Min
  • Beaker Volume：1000ml
  • Total Power Consumption：<700W
  • Dimension：400mm×300mm×250mm
  • Weight：10kg
  • Test Position：2 Units
  • Display：LCD
  • Test Method：Ring and Ball Apparatus
  • Application：Asphalt and Bitumen Testing
  • Function：Determine Softening Point of Petroleum Asphalt
  • Stirring Speed：(0~300) R,Min
  • Transport Package：Plywood Case
  • Specification：Automatic
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

1Power supplyAC(220V±10%)V, 50 Hz2Measurement range(1) Heating medium: 5 ºC~80 ºC distilled water(softening point ≤80 ºC)
(2) Heating medium: 32 ºC~160 ºC glycerin (softening point > 80 ºC)3Temperature resolution0.1 ºC4Heating rateit will be adjusted to (5.0±0.5) ºC/ min automatically after three minutes5Stirrer the electromagnetic stirring speed can be adjusted continuously, the stirring speed is (0~300) r/min6Beaker volume1000ml7Working conditionEnvironmental temperature:15ºC~35ºC;
Relative humidity: ≤ 85%8Total power consumption<700 W9Dimension400mm×300mm×250mm





Factory overviewAutomatic Ring and Ball Test Instrument for Softening Point of Bitumen by ASTM D36
Customer Feedback

Germany
Automatic Ring and Ball Test Instrument for Softening Point of Bitumen by ASTM D36
USA
Automatic Ring and Ball Test Instrument for Softening Point of Bitumen by ASTM D36
Package
Automatic Ring and Ball Test Instrument for Softening Point of Bitumen by ASTM D36
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
