• Model NO.：A91
• Heating Speed：120ºC,Min
• Pressure Setting Range：0-100psi
• Flow Setting Range：0~1000ml,Min
• Maximum Split Ratio：1:7500
• Application：Liquefied Petroleum Gas
• Column 1：20m*530um ID*5um
• Column 2：10m*530 U ID*10 Ulowox
• Column 3：30m*0.53
• Color：White
• Price：Low
• Language：English
• Transport Package：Plywood Case
• Specification：Stainless steel
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. A91 Heating Speed 120ºC/Min Pressure Setting Range 0-100psi Flow Setting Range 0~1000ml/Min Maximum Split Ratio 1:7500 Application Liquefied Petroleum Gas Column 1 20m*530um ID*5um Column 2 10m*530 U ID*10 Ulowox Column 3 30m*0.53 Color White Price Low Language English Transport Package Plywood Case Specification Stainless steel Trademark AI Origin China HS Code 9031809090 Production Capacity 20 Sets/Month

Product Description

IntroductionThe gas chromatograph is equipped with an automatic gas flow control module in the inlet, detector, and auxiliary gas module.
The hydrogen flame ionization detector can be automatically ignited, hydrogen leakage is automatically protected, and it is safe and reliable. The special ceramicized amplification board is always stable in the wet season.
This gas chromatography is equipped with fully imported gas and liquid valves, which can be automatically controlled, sequence operation, stable performance and convenient operation. The current mainstream imported capillary chromatographic column is used in the scheme configuration, which has excellent performance and long service life, can achieve good separation effect and peak shape, and improve the accuracy and stability of analysis. 2 Configuration

Item	CAT NO.	DESCRIPTION	QTY
1	G2091A	A91 Plus CG	1
2	G2011B	Software	1
3	1790M	Start-up kit A(including sample injection port))
4	#210	FID	2
5	#120	SISL Capillary Injection Port (0~100 psi)	1
6	PN5.132.002	One way PCM Pressure Control Module	1
7	#513	Three automatic valves,with valve box heating and pipeline	1
8	#561	Six way rotor valve	2
9	#450	Independent heating column(at the back of FID detector)	1
10	#515	Side Valve Box	1
11	#542	Four way liquid injection valve(1.0ul volume,75C and 1000 psi max)	1
12	#360	Liquid injection valve back pressure damping system assembly	1
13	ECM.7.342.001	2um stainless steel gas filter	1
14	#610	Sample ring(0.5mL)	1
15	PN5.150.006	Deoxidation trap	1
16	PN5.150.004	Dewatering trap	1
17	PN5.150.005	Dealkylation trap	1
18	Pipeline	Capillary column 1m*0.53	1
19	Column 1	20m*530um ID*5um MXT-1,Restek Cat.No.71812	1
20	Column 2	10m*530 u ID*10 uLowox	1
21	Column 3	30m*0.53	1
22	Computer	Lenovo	1


Factory overview

Customer Feedback

Germany

USA

Package

FAQ
1.What's the delivery time?
About 30 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
