49L Table Model Temperature Humidity Climatic Test Chamber
Dongguan Xin Bao Instrument Co., Ltd.- Certification：CE, ISO
- Refrigerant：R23,R404A
- Controller：Programmable LCD Touch Screen
- Compressor：Original France Tecumseh
- Waterway Device and Circuit Devices：Separated
- Color：Can Be Customized
Base Info
- Model NO.：XB-OTS-49
- Quality：Certificated
- Casters：Easy Mobility and Safe
- Transport Package：Strong Wood Case for Climatic Chamber
- Specification：(W*H*D)40*50*40CM
- Trademark：OTS
- Origin：Guangdong, China (Mainland)
- HS Code：8479899990
- Production Capacity：258 Pieces,Month
Description
-70°C~+150°C(180°C)
(A:-20°C B:-40°C C:-60°C D:-70°C )Humidity range 20%~98%R.H.(10%-98%R.H/5%~98%R.H) Temp humidity
analytic accuracy
/ uniformity ±0.1°C;±0.1%R.H./ ±1.0°C;±3.0%R.H.is special optional condition. Temperature humidity
control accuracy/fluctuation ±1.0°C;±2.0%R.H./ ±0.5°C;±2.0%R.H. Heat/cooling time About 5.0°C/min;about 1.2°C/min (5~10°C/min is a special optional condition Inner and outer materials SUS#304 Stainless steel for inner chamber and Carton Advanced cold plate nano paint for outer. Insulation materials Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials Cooling system Air cooling/single segment compressor(-20°C) ,air and water double segment compressor
(-40°C~-70°C) Protection devices Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch,
super humidity over-temperature protection switch, fuse, failure warning system Parts Watching window,50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze Controller TEMI" South Korea"TEMI" "OYO" Japan's "OYO" Brand optional Compressor Original France"Tecumseh"brand Power 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz
Features:
*.High-texture appearance, the body adopted an arc shape, surface matte stripes processing, and flat-handle, easy to operate, safe and reliable.
*.Rectangular multi-layer glass View window, the use of guinea pigs observed in the test window witt anti-sweat heaters device prevents water gas condensate ,Knot, water droplets, PL fluorescent lamps to keep the inside lighting.
*.Door bunk isolated airtight packing, can be effectively isolated from the internal temperature of the leak
*.With external water supply system, convenient to supplement the cylinder water supply, and automatic recovery using.
*.Compressor cycling system used France"Tecumseh"brand which can effectively remove condenser pipe and between capillary Lubricating oil and whole series adopt environmental protection refrigerant (R23, R404, R507)
*.Controller uses the imported LED display screen, can display measured values and setting time
*.Controller with multisegment program editor and temperature and humidity can be fast (OUICK) or slope (SLOP) controlled.
*.Built-in mobile wheels allow easy movement and placed and has a strong positioning screw position.
Standard:
GB/Bb T2423.2-89 high temperature test method GB2423.1-89 test A: low temperature test method 6
Ab IEC60068-2-1 low temperature test method GJB150.4-1986 test at low temperature
EIA - 364-59 test at low temperature IEC60068-2-38 temperature cycle
IEC60068-2-78 constant temperature IEC60068-2-30 temperature cycle
EIA - 364-31C temp resistance GB/T2423.3 constant heat test methodRecommend ProductsCompany Profile
Manufacturing TechniqueCustomer PhotosCertificationsPacking&ShipingFAQ1.Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while considering of sea transportation, we can extend 2 months for our customers. If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2.What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3.Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
4.How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our officail website directly. Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
(A:-20°C B:-40°C C:-60°C D:-70°C )
analytic accuracy
/ uniformity
control accuracy/fluctuation
(-40°C~-70°C)
super humidity over-temperature protection switch, fuse, failure warning system
Features:
*.High-texture appearance, the body adopted an arc shape, surface matte stripes processing, and flat-handle, easy to operate, safe and reliable.
*.Rectangular multi-layer glass View window, the use of guinea pigs observed in the test window witt anti-sweat heaters device prevents water gas condensate ,Knot, water droplets, PL fluorescent lamps to keep the inside lighting.
*.Door bunk isolated airtight packing, can be effectively isolated from the internal temperature of the leak
*.With external water supply system, convenient to supplement the cylinder water supply, and automatic recovery using.
*.Compressor cycling system used France"Tecumseh"brand which can effectively remove condenser pipe and between capillary Lubricating oil and whole series adopt environmental protection refrigerant (R23, R404, R507)
*.Controller uses the imported LED display screen, can display measured values and setting time
*.Controller with multisegment program editor and temperature and humidity can be fast (OUICK) or slope (SLOP) controlled.
*.Built-in mobile wheels allow easy movement and placed and has a strong positioning screw position.
Standard:
GB/Bb T2423.2-89 high temperature test method GB2423.1-89 test A: low temperature test method 6
Ab IEC60068-2-1 low temperature test method GJB150.4-1986 test at low temperature
EIA - 364-59 test at low temperature IEC60068-2-38 temperature cycle
IEC60068-2-78 constant temperature IEC60068-2-30 temperature cycle
EIA - 364-31C temp resistance GB/T2423.3 constant heat test methodRecommend ProductsCompany Profile
Manufacturing TechniqueCustomer PhotosCertificationsPacking&ShipingFAQ1.Do you offer after-sales service? How can I ask for that? And how about the warranty? Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while considering of sea transportation, we can extend 2 months for our customers. If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2.What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3.Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
4.How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our officail website directly. Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
