Tissue Ball Burst Tester Toilet Paper Burst Strength Test
Hangzhou Yante Science and Technology Co., Ltd.- After-sales Service：Available
- Warranty：1 Year
- Type：Strength Testing Machine
- Load Way：Electronic Load
- Display：Digital
- Control：Computer Control
Base Info
- Model NO.：YT-BBT30
- Weight：0-100Kg
- Power Source：AC220V
- Measuring Range：0-30n
- Resolving Power：0.01n
- Indication Accuracy：Indication Error 0.5%
- Test Head Stroke：300mm
- Transport Package：Wooden Box
- Trademark：YANTE
- Origin：Hangzhou, China
- HS Code：9024800000
Description
Application Range
Toilet paper, paper handkerchief
Product Features
Ball screw and three guide shafts ensure smooth and precise transmission.
ARM processor, imported 24-bit analog-to-digital converter, fast control, accurate and fast calculation data.
Real-time display of tension-deformation curve.
Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.
With data memory and overload protection functions.
It can communicate with computer software (purchased separately).
Product FunctionBursting strength of paper towes, toilet paper, paper handkerchiefs, etc.
Executive Standard
GB/T 24328.7-2020
Technical Parameters
Toilet paper, paper handkerchief
Product Features
Ball screw and three guide shafts ensure smooth and precise transmission.
ARM processor, imported 24-bit analog-to-digital converter, fast control, accurate and fast calculation data.
Real-time display of tension-deformation curve.
Sudden power failure data storage function, data before power failure after power-on is retained and testing can be continued.
With data memory and overload protection functions.
It can communicate with computer software (purchased separately).
Product FunctionBursting strength of paper towes, toilet paper, paper handkerchiefs, etc.
Executive Standard
GB/T 24328.7-2020
Technical Parameters
| No. | Parameter item | Technical index |
| 1 | Power Supply | AC(100~240)V,(50/60)Hz,100W |
| 2 | Working Environment | Temperature(10~35)ºC, Humidity≤ 85% |
| 3 | Display | 10 inch color touch screen |
| 4 | Measuring range | (0~30)N |
| 5 | Display resolution | 0.001N |
| 6 | Indication error | ±0.5%( range 5%~100%) |
| 7 | Indication variability | ≤0.5% |
| 8 | Diameter of pressure ring | Φ89 or Φ50 ±0.2 mm |
| 9 | Probe stroke | 300mm |
| 10 | Ball diameter | Φ16 ± 0.05mm |
| 11 | Test speed | 125 ± 1 mm/min (1-1000mm/min Continuously adjustable) |
| 12 | Stretching speed | (1~500)mm/min(Can be adjusted arbitrarily) |
| 13 | Built-in thermal printer | |
| 14 | Communication Interface | RS232(Default) (USB, WIFI optional) |
| 15 | Dimension | 550×470×930 mm |
| 16 | Net Weight | 71kg around |
