• Model NO.：FTH Series
• Accuracy：0.1degree C; 0.1% R.H
• Uniformity：+,-2.0degree C; +,-3.0% R.H.
• Temperature Rising/Falling Speed：3~30degree C,Min, Adjustable
• Test Hole：Dia. 50mm
• Transport Package：Wooden Case
• Specification：CE Certified
• Trademark：ASLi
• Origin：Guangdong, China
• HS Code：85141090
• Production Capacity：100 Sets,Month

Overview Product Description

Industrial Programmable High and Low Temperature Rapid Change Tester is used to test various types of materials for their tolerances of heat,cold, dry, humidity. It is appliedfor quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.


Inner door with operation hole (optional)
50mm or100mm   Entrance hole for test wire, Dia.50mm or 100mm
Sample Shelves, two layers
RS-232 or RS-485 communication

High and Low Temperature Rapid Change Tester Features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips. Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for observation of  sample under test,with interior lights
3.  Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4.  Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5.  French Tecumseh  is used as compressor, with environment friendly refrigeration R23,R404A
6.  LCD display screen is used for the control unit, capable of displaying set point and actual point at the same time
7. The control unit has the functions of multiples segment program editing
8. Quick or ramp rates control of  temperature and humidity.
9. Casters are provided for ease of mobility, with strong positioning screws.
 Product ParametersIndustrial Programmable Temperature Rapid Change Tester Pictures :Temperature Range: -70~+150degree C;
Range of Fast Temperature Change: -45~+85degree C;
Max. temperature rising/falling  speed is 15degree C/min when the whole process with linear control .Humidity Range(Optional)20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional ,need Dehumidifier)Indication resolution/
Distribution Uniformity
of Temperature and Humidity0.1degree C; 0.1% R.H/±2.0degree C; ±3.0% R.H.Control Accuracy of
Temperature and Humidity±0.5degree C; ±2.5% R.H.Temperature Rising/
Falling  VelocityRising/Falling Speed Rate with linear control : 3~15degree C/min, adjustable
Rising/Falling Speed Rate non-linear control : 3~30degree C/min, adjustableMaterialInterior material is SUS 304# stainless steel,e*terior is stainless steel or  SEE cold-rolled steel with paint coated.Insulation MaterialResistant to high temperature, high density, formate chlorine, ethyl acetum foam
insulation materials Cooling SystemWater cooled/single segment compressorProtection DevicesFuse-free switch, overloading protection switch  for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protectionOptional AccessoriesInner door with operation hole(Optional),  Water Purifier, DehumidifierCompressor French Tecumseh Brand, Germany Bizer BrandPowerAC380V 3Ph 5 lines, 50/60HZ Approx. Weight(Kg)250350450600 Detailed Photos

If you have any doubt or needs about Industrial Programmable High and Low Temperature Rapid Change Tester, please feel free to contact us.
