Three-phase Multifunctional Electric Energy Meter Verification Device
Wuhan GDZX Power Equipment Co., Ltd.- After-sales Service：Provide lifelong after-sales service
- Warranty：1 Year
- Voltage Output range：automatic range: 0V~600V
- Current AC range：Automatic range: 0A~25A
- Frequency Regulation fineness：45HZ~65Hz
- Phase Regulation range：0~360
Base Info
- Model NO.：ZX3030F
- Power accuracy：0.05%(reactive power: Less than or equal to 0.2%)
- Harmonic component：2~31order, amplitude: 0-40%
- Working temperature：-20~40Centigrade
- Reltative humidity：10%~90%
- Power supply：220V+,-10%, 48 HZ~51HZ
- Transport Package：Carton,Wooden Case
- Specification：With the change of technical scheme
- Trademark：GDZX
- Origin：Hubei
- Production Capacity：500 Pieces,Month
Description
1. State Variables output
1) Binary code "1" represents "close", "0" means "open"
2) Stage varables rating voltage: 24V/48V/110V/220V
3) Output current: max 200mA
4) Channels: 8 independent outputs
2. Pulse output
1) frequency: 0-5KHz adjustable
2) Pulse width: 0.1ms-100ms adjustable
3) Electric level: 24V/48V/110V/220V
4) Pulse number: output number can be set
5) Telecontrol protocol
6) CDT protocol shall conform to DL451-91
7) POLLING protocol shall confirm to DL/T634-2002
3. Working power supply: AC220V±10%
About GDZX
Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.
Shipping and packaging
Features1. Function: AC sampling device and sampling RTU (Remote Terminal Unit) calirbation
1) AC/DC analog value input measurement
2) state variables input measurement
3) remote control execution testing
4) remote regulation function testing
5) digital value input testing
6) impulse input testing
2. AC Power source
It can output AC voltage, AC current
accuracy 0.05 class
can provide standards of AC/DC voltage/current, power, phase, power factor, frequency, energy.
Output method and output electric quantity can be set arbitrarily
3. Data management
It can save, search, browse, print or delete RTU testing data.
Calibrated parameters can be saved permanently
