• Model NO.：EPRC-200A
• Weight：Tester:6.4kg, Accessories Carrycase: 9kg
• Power Source：220V or 120V at Customized
• Test Current：50A, 100A, 150A, 200A
• Measuring Range：100mohm50A,0-50mohm100A,0-20mohm150A,0-20mohm200A
• Resolution：Min. 0.1uohm
• Precision：+,-(0.5%+,-2 Digits)
• Power：1000W
• Touch Screen：Seven-Inch
• Working Duration：Continuously
• Working Supply：AC220V+,-10% 50Hz
• Working Temperature：0~40degree
• Relative Humidity：Less Than 90% No Condensation.
• Size：360mm*290mm*170mm
• Printer：Yes, Build-in
• Communication：Bluetooth, RS232, USB
• Computer Communication：U Disk
• Wiring Method：Four-Terminal
• Transport Package：Plywood Case with Foam Inside
• Specification：360mm*290mm*170mm
• Trademark：EP Hipot Electric
• Origin：Wuhan, China
• HS Code：903033200
• Production Capacity：1000,Year

Basic Info.

Model NO. EPRC-200A Weight Tester:6.4kg, Accessories Carrycase: 9kg Power Source 220V or 120V at Customized Test Current 50A, 100A, 150A, 200A Measuring Range 100mohm50A,0-50mohm100A,0-20mohm150A,0-20mohm200A Resolution Min. 0.1uohm Precision +/-(0.5%+/-2 Digits) Power 1000W Touch Screen Seven-Inch Working Duration Continuously Working Supply AC220V+/-10% 50Hz Working Temperature 0~40degree Relative Humidity Less Than 90% No Condensation. Size 360mm*290mm*170mm Printer Yes, Build-in Communication Bluetooth, RS232, USB Computer Communication U Disk Wiring Method Four-Terminal Transport Package Plywood Case with Foam Inside Specification 360mm*290mm*170mm Trademark EP Hipot Electric Origin Wuhan, China HS Code 903033200 Production Capacity 1000/Year

Product Description

General Information:
The EPRC Micro Ohmmeter is a high-precision, digital switch detection instrument which conforms to the IEC standards. The instrument uses high-power constant-current switching power supply technology to measure micro-ohmic contact resistance. It is widely used for measuring the contact resistance, loop resistance of various switches and electrical appliances, and the contact resistance of cables, wires, and welds.

Features:

• It has multiple protection functions such as back-EMF impact, test line interruption, power failure, and overheating of the power supply. It can reliably protect the back-EMF impact on the instrument and sound the alarm synchronously.
• Intelligent power management technology, the instrument always works in the minimum power state, effectively saving energy and reducing heat.
• The output voltage is high and the measurement range is wide.
• The test current comes from a high-precision high-current constant-current power supply. No need manual adjustment is required, and the test is quick and accurate.
• The four-terminal wiring method effectively eliminates the influence of test line resistance on the test results.
• Seven-inch high-brightness touch color LCD, clear display under strong light, full touch screen operation.
• Perpetual calendar clock and power-off storage, which can store 1000 sets of test data, which can be consulted at any time
• Bluetooth communication, RS232 communication and USB interface for computer communication and U disk data storage.
• Built-in micro printer.

Technical Specifications:


Test Current:	50A, 100A, 150A, 200A
Measuring Range:	0 ~ 100mΩ(50A)    0 ~ 50mΩ(100A) 0 ~ 20mΩ(150A) 0 ~ 20mΩ(200A)
Resolution:	Min. 0.1µΩ
Precision:	±(0.5%±2 digits)
Power:	1000W
Working duration:	continuously
Working Supply:	AC220V±10% 50Hz
Working temperature:	0~40ºC
Relative Humidity:	≤90% no condensation.
Oversize:	360mm*290mm*170mm
Weight:	Tester:6.4kg, Accessories carrycase: 9kg

More details on 100A 200A Micro Ohmmeter Contact Resistace Tester please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
