• Model NO.：HT-344
• Testing Before Delivery：Yes
• OEM Service：Yes
• Transport Package：Wooden Packing
• Trademark：DahoMeter
• Origin：Dongguan, China
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. HT-344 Testing Before Delivery Yes OEM Service Yes Transport Package Wooden Packing Trademark DahoMeter Origin Dongguan, China Production Capacity 300 Sets/Month

Product Description

HT-344 Leading Manufacture Offer EN Sole Bending Testing Machine


Application

The sole bending tester measures the bending resistance of the sole material under the action of continuous bending. Before the test, a number of holes were punctured in the place where the sole was most bent. The two ends of the sole test piece were fixed between the clamps. During the test, one end of the clamp was fixed and one end was movable. After a certain number of tests, remove the test piece to check the bending change.

Standards

EN-344

Specification


Bending angle	90 °
Round shaft diameter	φ30mm
Bending speed	0 ~ 135 revolutions / minute
Fixture width	144mm
Testing at the same time	3 soles
Counter	LED, 0 ~ 99999999
Horsepower	DC, 375W
Volume	85 × 31 × 65cm
Weight	68kg
Power source	1∮, AV220V, 3A



Company Information

We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.
