Automated External Type CNG Cylinder Hydrostatic Test Machine Price

Wuxi Longterm Machinery Technologies Co., Ltd.
  • After-sales Service：Online Video Guidence
  • Warranty：One Year
  • Max Diameter of Workpiece：540mm
  • Mass Scope of Workpiece：<900kg
  • Type：Gantry-Type Online External Hydro Testing
  • Maxcapacity：>1000KN

Base Info

  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：1000-2000Kg
  • Power Source：AC380V
  • Oil Cylinder Position：Top
  • Length of Gas Cylinder：800-2700mm
  • Diameter：279-540 mm
  • Volume：40-310L
  • The Weight of The Gas Cylinder：Below 150kg
  • Electricity：415V, 50Hz
  • System Design Pressure：50 MPa
  • Water Pressure Test Pressure：20-40MPa
  • Accuracy of Pressure Sensor：0.25%
  • Beat：16-20 PCS,Hour,Set
  • Accuracy of Electronic Scale：200g
  • Product Name：Automatic Gantry External Hydro-Static Testing
  • Transport Package：Standard Seaworthy Package
  • Specification：ISO9001
  • Trademark：HLT
  • Origin：Jiangsu, China
  • HS Code：9024800000
  • Production Capacity：300 Sets,Year

Description

Automated External Type CNG Cylinder Hydrostatic Test Machine PriceCylinder parameters

1. Length of gas cylinder: 800~2700mm
2. Diameter: 279~540 mm
3. Volume: 40~310L
4. The weight of the gas cylinder: ≤150Kg
(3) On-site working environment
1. Relative humidity: ≤85%
2. Compressed air: 0.4~0.7MPa
3. Saturated steam: ≥140ºC, 0.5Mpa
4. Electricity: 415V±10% 50Hz±2Hz
5. The driving track height of the workshop: 7m
(4) Technical specifications and requirements
1. Production program and usage: 8 hours/shift, 2 shifts/day, 252 days/year.
2. Beat: 16-20 pcs/hour/set (including loading and unloading time, taking 65L steel gas cylinder as an example, holding pressure for 30s)
3. System design pressure: 50 MPa
4. Water pressure test pressure: 20~40MPa
5. Minimum resolution of residual deformation: 0.1g
  6. Water volume measurement accuracy: ≤0.1ml
7. Gas cylinder weighing range: 600kg, accuracy of electronic scale: 200g
8. Accuracy of pressure sensor: 0.25%
9. Precision pressure gauge: 0.25 level (PSI, MPa double reading value) Working pressure gauge: 1.0 level
10. Saturated steam temperature/pressure: 150ºC/0.4-0.5MPa
 Automated External Type CNG Cylinder Hydrostatic Test Machine PriceFAQQ: How can we guarantee quality?
A: Always a pre-production sample before mass production; Always final Inspection before shipment;

Q: What can you buy from us?
A: All the machine for the CNG cylinder production line.

Q: Why should you buy from us not from other suppliers?
A: Wuxi Longterm Group is group corporation which are professional supplier of cable, LPG gas cylinder, steel drum, LNG and CNG
machinery with more than 25 years of experience and a strong professional R & D team

Q: What services can we provide?
A: Online technical support, On-site installation, Spare parts...

We need to know the following information to make the quotation to you:1. The technical drawing of the cylinder.
2. Daily capacity.
Welcome to inquiry!
