• Model NO.：AT851
• Resistance Max Display：2200
• Battery Capacity Test：0-999ah
• Name：At851,30 W, 120 V, 30 a Battery Aging Tester
• Transport Package：Carton
• Specification：CE, ISO9001
• Trademark：APPLENT
• Origin：Jiangsu, China
• HS Code：9030332000
• Production Capacity：3000sets,M

Battery aging tester

Rated Input

300W, 120V, 30A

CC

0 ~ 3A, Accuracy: 0.05%, Minimum Resolution: 0.0001A

0 ~ 30A, Accuracy: 0.1%, Minimum Resolution: 0.001A

CV

0 ~ 18V, Accuracy: 0.05%,  Minimum Resolution of 0.001V

0 ~ 120V, Accuracy: 0.05%, Minimum Resolution of 0.01V

CP

0 ~ 100W, Accuracy: 1%, Minimum Resolution: 0.001W

0 ~ 150W, Accuracy: 1%, Minimum Resolution: 0.01W

CR

0.1 ~ 99Ω, Accuracy: 1%, Minimum Resolution: 0.01Ω

100 ~ 4kΩ, Accuracy: 1%, Minimum Resolution: 0.1Ω

Monitoring

Voltmeter accuracy:0.02%; ammeter accuracy: 0.1%; battery charging time: 0 - 1000 hours; battery power check: 0 - 999AH, battery rest time: 0 - 1000 hours; battery cycle times: 1 - 10000 times; speed: 3 times/second, 10 times/times

Short-circuit Test

Current about 30A, the internal resistance of about 40mΩ

Transition

10 files, 0.1Hz ~ 1kHz

List Test

10 documents, 100 steps / file

Test file

10 files, 20 steps / file

Trigger

Internal, External, BUS trigger

Interface

RS232 and handler interface

Programmable Language

SCPI and simple communication protocol

Protection

Level 5 safety protection

Others

VFD display, 4W remote sensing capability, intelligent cooling

GENERAL FEATURES

Power Supply

Voltage: 220V AC  Frequency: 50Hz  Power: 20VA (Max)

Size

216mm (Width)*88mm (Height)*300mm (Depth) 3kg

ORDERING INFORMATION

Accessory

ATL509 test cable
