2000kn Servo-Hydraulic Universal Testing Machine

Wuxi Serve Real Technology Co., Ltd.
  • Max Diameter of Workpiece：<500mm
  • Mass Scope of Workpiece：<900kg
  • Type：Material Testing Machine
  • Maxcapacity：>1000KN
  • Accuracy Grade：1
  • Load Way：Electronic Load

Base Info

  • Model NO.：UTM-2000D
  • Loading Method：Hydraulic Loading
  • Display：Digital
  • Control：Computer Control
  • Weight：>2000Kg
  • Power Source：AC380V
  • Oil Cylinder Position：Under
  • Delivery Time：10-15 Days
  • Payment：Paid Before Shipment
  • Warranty Period：24months
  • Onsite Installation：Yes
  • Supply Area：Global
  • Protection Shield：Optional
  • Customized：Yes
  • Transport Package：Wooden Case
  • Specification：UTM
  • Trademark：SERVE REAL
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：200sets,Year

Description

Max testing force

2000kN

Accuracy degree

0.5(0.5%)

Test force measuring range

0.4%-100%, stepless, equivalent 4 steps

Force indication value relative error

<±0.5%

Test load resolution

1/500000

Deformation indication value relative accuracy

<±0.5%

Deformation resolution

1/300000

Max tensile test space

1100mm

Compression space

950mm

Piston stroke

300mm

Cylinder sample max clamping range

Φ20mm-Φ90mm

Flat sample max clamping thickness

0-70mm

Flat sample max clamping width

140mm

Platen size

Φ300mm, HRC>55

Clamping mode

Hydraulic

Main machine overall size

L1200mm×W850mm×H3400mm

Controller size

1100mm×750mm×1000mm

Motor total power

4.5KW

Net weight

9000KG

2000kn Servo-Hydraulic Universal Testing Machine
2000kn Servo-Hydraulic Universal Testing Machine2000kn Servo-Hydraulic Universal Testing Machine2000kn Servo-Hydraulic Universal Testing Machine
