Analog Type Universal Testing Machine with Dial Gauge(WA-300D/600D/1000D)

Nanjing T-Bota Scietech Instruments & Equipment Co., Ltd.
  • After-sales Service：yes
  • Warranty：one-year
  • Type：Universal Testing Machine
  • Maxcapacity：<1000KN
  • Accuracy Grade：1
  • Load Way：Electronic Load

Base Info

  • Model NO.：WA-300D,600D,1000D
  • Loading Method：Dynamic Load
  • Display：Needle
  • Control：Computer Control
  • Weight：100-500Kg
  • Power Source：AC220V
  • Oil Cylinder Position：Under
  • Max. distance between flexible clips (in：600
  • Max. ram travel (mm)：200
  • Time for Load Maintained (s)：≥ 30s
  • Accuracy (from 20% of the full testing r：Grade 1
  • Transport Package：Standard Export Packing
  • Specification：ISO9000
  • Trademark：TBT
  • Origin：Nanjing, China
  • HS Code：90158790
  • Production Capacity：50 Sets Per Month

Description

Overview Product Description

Mainly used in metal tensile, compression, shear and bending tests. Coupled with appropriate fixtures, it is also applied in compression tests of concrete, masonry and other non-metallic materials. It is a must-have for scientific research institutes, metallurgy and mechanical manufacturers, quality Inspection stations and institutions of higher education.

Product Parameters

 1. Max Capacity (kN)WA-1000DWA-600DWA-300D2. Measuring Range (kN)0 ~ 200, 0 ~ 500, 0 ~ 10000 ~ 120, 0 ~ 300,   0 ~6000 ~ 60, 0 ~ 150,   0 ~3003. Accuracy (from 20% of the full testing range)Grade 1Grade 1Grade 14. Time for Load Maintained (s)≥ 30s≥ 30s≥ 30s5. Max. distance between flexible clips (including ram travel)6006006006. Distance between upper and lower platens0 ~ 5000 ~ 5000 ~ 5007. Distance between two fulcrums of bending test100 ~ 420100 ~360100 ~3608. Cliping diameter for round specimenΦ 20 ~Φ 60Φ 13 ~Φ 40Φ 8 ~Φ 329. Cliping thickness for flat specimen0 ~ 400 ~ 150 ~ 1510. Max. ram travel (mm)20020015011. Max rising speed of the ram (without load mm/min)0 ~ 800 ~ 800 ~ 8012. Dimensions (L*W* H)Main frame (mm*mm*mm)960*620*2150880*600*2020740*460*1970Console (mm*mm*mm)600*660*1780600*600*1780600*600*178013. Net Weight (Kg)Main frame220017001200Console400400400




Customer Visit



Business Scope

Analog Type Universal Testing Machine with Dial Gauge(WA-300D/600D/1000D)

Packaging & Shipping

Analog Type Universal Testing Machine with Dial Gauge(WA-300D/600D/1000D)

Clients Feedbacks

Analog Type Universal Testing Machine with Dial Gauge(WA-300D/600D/1000D)

FAQ



1. How long is the delivery time?
Normally goods will be shipped out within 7-10days after contract signed and down payment received.

2. Is it possible to make our own brand/logo on your product?
Yes, but depends on MOQ.

3. What's your MOQ?
This depends on different types of products. If it is a large machine, the MOQ is usually 1 set. For small instruments, such as thermometers, the MOQ is 50 pieces.

4. What kind of payment term you accept?
Normally,
1) If total contract value less than USD 10,000.00 : 100% T/T in advance after contract signed.
2) If total contract value more than USD 10000.00 : 50% T/T in advance after contract signed and 50% T/T after receipt of BL copy. Or, irrevocable LC is acceptable.
