• Model NO.：THV-1000
• Temp. Constancy：< or =0.5oc
• Temp. Uniformity：+,-2.0oc
• Humidity Range：2.0%R.H.~98%R.H.
• Cooling Rate：Less Than 5oc,Min or Less Than 10oc,Min
• Interior Material：Stainless Steel Plate(SUS304)
• Exterior Material：Baked Painting Steel or Stainless Steel (SUS304)
• Insulation Material：Rigid Polyurethane Foam
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets Per Yesr

Specifications ModelTHV-4081000Working chamber volume ( L )4081000Interior size ( W*H*D ) mm600*850*8001000*1000*1000Safety deviceNo fuse breaker, overpressure overheat and
over current protection for compressor, Over temp. protection, overload protection for the blower, Hydraulic and Water lack Protection dry heat protection PowerAC 380V/50Hz,3phase 5 wires+ ground wire Temp regulating modeBalanced Temperature & Humidity Control System ( BTC )Ambient temp +5 ºC~ +35 ºCPerformanceTemp range -70 ºC~ +150 ºCTemp constancy≤0.5 ºCTemp uniformity±2.0 ºCHumidity constancy±2.5%RHHumidity range2.0%RH ~ 98%RHHumidity uniformityIf humidity≤75%RHJ, ±3.0%RH ; f humidity > 75%RHJ, ±5.0%RHCooling rate≤5  ºC /Min or ≤10  ºC /Min  ( -55 ºC~ +80 ºC  within humidity range )MaterialExterior materialCold-rolled steel sheet (Rustproof & Plastic Spray treated )/ Stainless Steel plateInterior materialStainless steel plate(SUS 304)Insulation materialRigid polyurethane foamCooling systemcompressorSemi-Hermetic CompressorCooling modeWater-cooledHeaterIron-chrome wire heaterBlowerCentrifugal BlowerSight window470mm*350mm   Glass incorporating heat generatorTemp sensorPt-100 ControllerTouch screen controllerShaking tableCustom made as requiredNote:
1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
Packaging
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

After-sale service
If you face any problems in the future during the testing process we promise we will give you a reply within 48 hours and the solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by the customer.
