• Model NO.：OST-525
• Working Unit：2 Bombs
• Power Supply：AC220 V 50Hz
• Operation：Automatic
• Printer：Inbuilt
• Application：Gasoline Oil Testing
• Temperature Control Range：100±0.1ºC
• Power Consumption：1.5kw
• Dimension：630 * 560 * 490mm
• Weight：42kg
• Control：Touch Screen
• Language：English
• Transport Package：Plywood Case
• Specification：Small
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. OST-525 Working Unit 2 Bombs Power Supply AC220 V 50Hz Operation Automatic Printer Inbuilt Application Gasoline Oil Testing Temperature Control Range 100±0.1ºC Power Consumption 1.5kw Dimension 630 * 560 * 490mm Weight 42kg Control Touch Screen Language English Transport Package Plywood Case Specification Small Trademark AI Origin China HS Code 9031809090 Production Capacity 20 Sets/Month

Product Description

Introduction

This oxidation stability testing equipment is used to determine the stability of gasoline in finished form only, under accelerated oxidation conditions.The induction period may be used as an indication of the tendency of motor gasoline to form gum in storage.



Characteristic

1. This oxidation stability testing equipment can automatically fill and discharge oxygen,automatic detect leakage.

2. The test equipment can make Pressure-Time curve in real time,automatic judge turning point.

3. Dual independent oxygen bombs,won't influence each other during test.

4. The oxidation stability testing equipment adopts big colorful touch screen is convenient to operate.

5. Over-temperature protection device has power off protection when temperature is higher than set temperature.

6. Bomb auxiliary heating device makes uniform temperature field.



Technical specifications

1. Applicable standard: GB/T8018, ASTM D525,ISO7536, DIN51780, IP40;
2. Temperature control mode: PID temperature control technology, automatic temperature control;
3. Temperature control accuracy: 100 ± 0.1 ºC;
4. Display contents:
control temperature and set temperature;
Sample number;
logarithmic curve of time / pressure (two channels are displayed at the same time);
Test results;
Fault prompt, etc
5. Working unit: two oxygen bombs;
6. Pressure correction: the external pressure regulator can correct the pressure deviation;
7. Connection mode: imported stainless steel quick connector connection, no leakage;
8. Power consumption: 1.5kw;
9. Working power supply: 220V 50Hz;
10. Instrument size: 630 * 560 * 490mm;
11. Net weight: 42kg.


Factory overview

Customer Feedback

Germany

USA

Package

FAQ
1.What's the delivery time?
About 30 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
