• Model NO.：EP-DVDF
• Weight：500-1000Kg
• Power Source：AC380V
• Full Protection Functions：Over-Current, Over-Voltage, Zero-Start Light Alarm
• Designed for：Generator Set Controlling
• Controlled by：Push Button
• Phase and Line：3 Phase 4 Lines
• Output Frequency：150Hz
• Output Current：15A@30kVA
• Rated Capacity：30kVA or at Customized
• Output Voltage：800V or at Customized
• Generator Input Voltage：380V
• Generator Input Frequency：50Hz
• Motor Running Current：14A@30kVA
• Excitation Current：18A@30kVA
• Rated Speed：1480r , Min
• Excitation Voltage：185V@30kVA
• Excitation Frequency：50Hz
• Transport Package：Plywood Case
• Specification：1560*480*770
• Trademark：EP Hipot Electric
• Origin：Wuhan, China
• HS Code：9031809090
• Production Capacity：500,Year

Basic Info.

Model NO. EP-DVDF Weight 500-1000Kg Power Source AC380V Full Protection Functions Over-Current, Over-Voltage, Zero-Start Light Alarm Designed for Generator Set Controlling Controlled by Push Button Phase and Line 3 Phase 4 Lines Output Frequency 150Hz Output Current 15A@30kVA Rated Capacity 30kVA or at Customized Output Voltage 800V or at Customized Generator Input Voltage 380V Generator Input Frequency 50Hz Motor Running Current 14A@30kVA Excitation Current 18A@30kVA Rated Speed 1480r / Min Excitation Voltage 185V@30kVA Excitation Frequency 50Hz Transport Package Plywood Case Specification 1560*480*770 Trademark EP Hipot Electric Origin Wuhan, China HS Code 9031809090 Production Capacity 500/Year

Product Description

EP-DVDF
Inductive Withstand Voltage (DVDF) Test System

General Information:
DVDF Test System mainly designed for transformer induction withstand voltage test and partial discharge test.

DVDF Control Table:

• 3 phase 4 lines
• Controlled by push button.
• Designed for generator set controlling.
• High anti interference ability
• Full protection functions: over-current, over-voltage, zero-starting light alarm.
• During testing process, press exit button to quit any tests. Press Emergency button if any abnormal happened.
• Digital voltage/current meter, precision 1.5 degree.
• Power source: 3 phase

The system is consisted by below units:

• Generator Motor Set                        EPYZR          1set
• Generator Set Controlling Table      EP-DVDF       1set

Motor Generator Set Main Specifications:


Power (kVA)	Output Frequency (Hz)	Operating Current(A)	Exciting Voltage(V)	Exciting Current(A)	Rated Output Current(A)	Rated Output Voltage(V)
30	150	9-14	140-185	15-18	15	800
30	150	9-14	140-185	11-25	9.5	1400
30	100	9-14	140-185	11-18	16	800
40	150	9-11	130-140	18-19	20.1	800
50	150	14-19	130-185	22-30	24.5	800
50	150	14-19	130-185	22-35	32	1400
50	100	14-19	140-185	22-30	16	800
60	150	19-24	100-150	11-18	32.5	800
60	150	19-24	170-220	28-38	22	1400
60	100	19-24	170-220	11-18	33	800
75	150	17-26	210-250	35-42	41	800
75	150	17-26	240-300	40-48	24	1400
75	100	17-26	210-250	34-40	42	800

Rated capacity: 30kVA
Generator input voltage: 380V
Generator input frequency: 50Hz
Generator input current: motor running current 14A, excitation current 18A
Rated speed: 1480r / min
Excitation voltage: 185V
Excitation current: 18A
Excitation frequency: 50Hz
Output voltage: 800V
Output current: 15A
Output frequency: 150Hz

Rated capacity: 40KVA
Generator input voltage: 380V
Generator input frequency: 50Hz
Generator input current: motor running current 15A, excitation current 19A
Rated speed: 1480r / min
Excitation voltage: 140V
Excitation current: 19A
Excitation frequency: 50Hz
Output voltage: 800V
Output current: 23A
Output frequency: 150Hz

Rated capacity: 50kVA
Generator input voltage: 380V
Generator input frequency: 50Hz
Generator input current: motor operating current 19A, excitation current 25A
Rated speed: 1480r / min
Excitation voltage: 150V
Excitation current: 25A
Excitation frequency: 50Hz
Output voltage: 800V
Output current: 24.5A
Output frequency: 150Hz


Rated capacity: 74kVA
Generator input voltage: 380V
Generator input frequency: 50Hz
Generator input current: motor running current 23A, excitation current 35A
Rated speed: 1480r / min
Excitation voltage: 280V
Excitation current: 35A
Excitation frequency: 50Hz
Output voltage: 1400V
Output current: 21.0A
Output frequency: 150Hz


This series can be customized according the customer's requirements. More details on motor generator test set DVDF please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
