• Model NO.：BTS-SERIES
• Temp. Recovery Time：≤5mins
• Temp. Fluctuation：≤±0.5ºC
• Other：Provide a Complete Set of Security Test System Des
• Main Keyword1：Environmental Testing Chamber
• Main Keyword2：Temperature Test Chamber
• Transport Package：Each Set Protected with Resin Fiber and PP Film, T
• Specification：Test Space 350x400x360(customizable)
• Trademark：DGBELL
• Origin：Guangdong China
• HS Code：8419899090
• Production Capacity：100set ,Month

W x H x D (mm)External Dimension1320x1860x14201320x2180x15201450x2200x17001550x2280x18001800x2300x20002000x2350x2300W x H x D (mm)Pre-cooling Zone Temp.-10~-80ºCPre-heating Zone Temp.+50~+220ºCPre-cooling Zone Cooling Rate-10~-40ºC<30 mins     -10~-60ºC<50 mins     -10~-80ºC<65 minsPre-heating Zone Heating Rate+50~150ºC<30 mins   +50~180ºC<50 mins    +50~220ºC<60 minsTemp. Shock RangeB type :-40~150ºC   C Type :-55~150ºC     D Type :-65~150ºCTemp. Recovery Time≤5minsHigh low Temp. Exposure Time<30 minsTemp. Fluctuation≤±0.5ºCInternal Material1.2mm thick SUS#304 high &low temperature resistance stainless steel.External MaterialAdopt flame retardant high strength PU Polyurethane foam insulation material.Control MethodTouch screen programmable PLC, with USB interface, with RS485 interface can be connected to computer controlling, special network control software, convenient remote monitoring, data acquisition.CompressorTecumseh (France)-fully air-cooled double-fall cooling compressor. Or Bock (Germany) semi-enclosed air-cooled refrigeration.

Established in 2005, Guangdong Bell Experiment Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products which mainly include: Constant Temperature & Humidity Test Chamber,High & Low Temperature Test Chamber, High & low Temperature Testers with Rapid Temperature Change, Walk-In humidity & temperature test chamber, Cool/Thermal shock test chamber, Salt spray chamber, High temperature aging tester, sand and dust testing machine,tension tester, high and low temperature testing machine , servo computer battery crush tester, mechanical vibration testerBattery washing tester ,battery burning tester and other quality testing instruments. Thanks to several decades of R&D efforts,the company has established itself as a leading provider of testing instruments of the industry, playing a crucial role in the research and development of high-quality and high-value products within the industry.

15+ years experience in test chambers manufacturing, High performance for your projects.

With unmatched quality advantage, a dynamic management team, professional customer services, superb manufacturing techniques and innovative research and development ideas, Guangdong Bell Experiment Equipment Co., Ltd, supported by an international, standard and professional quality policy, is gradually becoming an international brand. Its products are manufactured in consistent with a number of world standards.

FAQ

Why choose us?
Q1 : Can you customize the product?
   A:  Yes, we can customize any products according to requirements. Hot selling lab electronic
        temperature humidity cabinet/Environmental climate test chamber/Car Battery Safety Test Chamber also can            be customized.

Q2 : How to choose the most suitable products?
   A:  Our professional team will give you the best suggestion, just be patiently to tell us the information
        about the parameters you require.

Q3 : Can you arrange installations and commissioning in our lab?
   A:  Firstly, for standard chamber we had 3-5 days commissioning before shipping,
        you just need link power in your lab, then you can start to operate.
       Secondly, we had detailed operation manual with chamber , any problems you can find and solve in it.
       Thirdly, some customized chambers we should install and teach your team to operate .

How to Contact Us?

Please send your inquiry details below or send them to my mail below. We promise to reply to your inquiry on time.
