Industrial Hot Air Circulating Drying Oven
Guangdong Komeg Industrial Co., Ltd.- After-sales Service：24 Hours on Line Services
- Power Supply：AC380V 25Hz, 3 Phases
- Certification：CE, TUV, ISO
- Warranty：1 Year
- Interrior Dimension(W*H*D)Cm：60*95*50(Cm)
- Exterior Dimensions(W*H*D)Cm：90*161*64
Base Info
- Model NO.：KOV-290
- Temp. Range：50oc~200oc
- Temp. Constancy：+,-1.0oc
- Temp. Uniformity：+,-2.0oc
- Heat up Time：+,-20~+200oc Within 50mins
- Interior Material：Stainless Steel
- Exterrior Material：Baked Painting Steel
- Insulation Material：Glass Wool
- kVA：4.2
- Transport Package：Strong Plywood Case, Meet International Standard
- Specification：Standard and Customized
- Trademark：KOMEG
- Origin：Dongguan, China
- HS Code：90321000
- Production Capacity：1000 Sets Per Yesr
Description
No-Oxidation OvenSPECIFICATIONS Note: We reserve the right to change specifications without prior notice MODEL KNO-200 KNO-290 KNO-500 KNO-216D Temp. range 50 ºC~ 200ºC Temp. constancy ±1.0ºC Temp. uniformity ±2.0 ºC Heat up time ±20 ~ + 200 ºC about 50 Min Interior dimension 60W*65H*50D 60W*95H*50D 80W*105H*60D 60W*60H*60D Exterior dimensions 90W*170H*64D 90W*161H*64D 110W*173H*74D 151W*186H*78D Interior material Stainless steel Exterior material Baking painted steel Insulation material Glass wool Safety devices No Fuse Breaker, Over Temp. relay, ceramic fuse Accessories Recorder 30hr isolating layer *2, N2 or CO2 flow meter Capacity (KVA) 3 4.2 5.1 9 Power AC220V±10% 1Φ 50Hz/60Hz
