Ep Hipot Electric High Voltage Tester No Voltage Tester 0-500kv
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：No Voltage Tester
- Accuracy Grade：0.01
Base Info
- Model NO.：EP8510S
- Load Way：Electronic Load
- Display：3.5" True Color LCD
- Control：Computer Control
- Weight：0-100Kg
- Power Source：Battery
- Key Word：No-Voltage Tester
- Function：Wireless High Voltage Phase Voltage, Voltage to Gr
- Transmission：433 MHz Wireless
- Distance：Approx. 100m
- Electro Test：100V~500kv
- Voltage to Ground：100V~110kv
- Frequency：45.0Hz~55.0Hz
- Sampling Speed：2 Times,Sec
- Data Save：5000 Groups
- LCD Size：73 mm* 55mm, Display Area 69mm* 52mm
- Metal Hook：Outer Diameter 68mm
- Resolution：0.01kv (2.00kv~20.00kv)
- Insulation Rod Length：Carry on Length 0.7m, Stretched 3meters
- Collector：Lwt275mm * 105mm * 52mm
- Receiver：Lwt250mm * 100mm * 45mm
- Transport Package：Carton
- Specification：receiver: LWT250mm*100mm*45mm
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：9030899090
- Production Capacity：2000,Year
Description
Voltage accuracyFIY (100V~1000V) ±15%±5dgt (1kV~110kV,High voltage overhead lines, other application tolerance ±25%±5dgt) Frequency accuracy ±2Hz (0.1kV~110.0kV) Induction intensity During high-voltage power test, with the strength of the induced electric field, the electroscope will automatically adjust the 2kV, 20kV and 110kV gears, which are suitable for the places with dense lines. The 2kV gear is the default when the machine is started, and the induction is the strongest Sampling speed 2 times/sec Data save 5000 groups Insulation Rod length Carry on length 0.7meter, stretched 3 meters Meter size Collector: LWT275mm * 105mm * 52mm
Receiver: LWT250mm * 100mm * 45mm Overhead line volt The bare conductor below 110kV can be tested by direct contact; the bare conductor above 110kV must be tested by non-contact method; it can also be directly hung on the line with intact insulation sheath above 110kV for testing Contact electro test Contact electro test: when the collector is connected with a metal hook or probe, the metal hook or probe shall contact the bare wire to ensure the accuracy of power test and voltage test
More details on EP8510S Wireless High Voltage Electroscope 0-500kV please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
