DC/AC Transformation Technology Ground Pile Grounding Resistance Tester
Wuhan GDZX Power Equipment Co., Ltd.- After-sales Service：Provided
- Warranty：1 Year
- Temperature：0centigrade to +45centigrade
- Relative humidity：Less than or equal to 85%RH
- Voltage：AC 0-30V
- Resolution：0.001Ohm,0.01Ohm,0.1Ohm,0.01V
Base Info
- Model NO.：BY2571
- Maximum power dissipation：Less than or equal to 2W
- Power supply：AC 220V,50Hz,6.8V-9V 7*#5 rechargeable battery
- Main machine size and weight：220*200*105mm3,Less than or equal to 1.4kg
- Resistance：0-2Ohm(10mA),2-20Ohm(10mA),20-200Ohm(1mA)
- Transport Package：Wooden Case or Carton
- Specification：Universal Testing Machine
- Trademark：GDZX
- Origin：China
- Production Capacity：1200sets,Year
Description
Company introduction
Service and Warranty
Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user's questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others. Warranty* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.* Our products are guaranteed with one year warranty and life-long tech support.* Provide solutions within 24 hours when there is problems feedback from customer.
PACKING AND SHIPPING
(1)We will ship products within 8-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.(5)After shipping, we will remain attentive till goods well received. If you need detailed specification, please feel free to contact us.
Features
1.High-strength aluminum alloy shell body, the circuit equips with phase locked loop and switched capacitor filter, based on which the instrument play an effective role in shielding power frequency and radio frequency interference.
2.DC/AC converter can transform DC current into AC low-frequency constant current for the measurement.
3.Auxiliary grounding resistance are allowed to change in the range of 0 ~ 2KΩ (RC), 0 ~ 40KΩ (RP), that will not affect measurement results.
4.No need manual adjustment to zero, with three and a half bits LCD display, the instrument can be used for measuring the grounding resistance, low conductor resistance, soil resistivity and AC voltage to ground.
5.If tested loop encounter failure, the screen displays "1" indicating overflow, which consistent with conventional measurement practices.
