Stsj-6 Aggregate Vibrating Sieve Shaker
Shanghai Civil & Road Instrument Co., Ltd.- After-sales Service：24 Hours Online Support
- Warranty：1 Year
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Aggregate Testing Machine
- Maxcapacity：No
Base Info
- Model NO.：STSJ-6
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：No
- Display：Digital
- Control：No
- Weight：256kg
- Power Source：AC380V
- Oil Cylinder Position：No
- Product Name：Stsj-6 Electromechanical, Triple Motion, Sieve Sha
- Sieve Dia：Dia 200mm,Dia100mm,Dia75mm
- Sieve Layer：7 Layers
- Rotation：290times,Min
- Tapping：56times,Min
- Tapping Height：38mm
- Levelness of The Basement：Below 0.6mm,Min
- Rotation Distance：25 mm
- Motor Power：0.37kw
- Transport Package：Wooden Case
- Specification：0.5 CBM
- Trademark：SHTG
- Origin：China
- HS Code：9031809090
- Production Capacity：100PCS,Month
Description
Basic Info.
Model NO. STSJ-6 Accuracy Grade 1 Load Way Electronic Load Loading Method No Display Digital Control No Weight 256kg Power Source AC380V Oil Cylinder Position No Product Name Stsj-6 Electromechanical, Triple Motion, Sieve Sha Sieve Dia Dia 200mm,Dia100mm,Dia75mm Sieve Layer 7 Layers Rotation 290times/Min Tapping 56times/Min Tapping Height 38mm Levelness of The Basement Below 0.6mm/Min Rotation Distance 25 mm Motor Power 0.37kw Transport Package Wooden Case Specification 0.5 CBM Trademark SHTG Origin China HS Code 9031809090 Production Capacity 100PCS/MonthProduct Description
STSJ-6 Electromechanical, triple motion, sieve shakerSpecification:
| Product name | STSJ-6 Electromechanical, triple motion, sieve shaker |
| Sieve Dia | φ200mm,φ100mm,φ75mm |
| Sieve layer | 7 layers |
| Rotation | 290±6 times/min |
| Tapping | 156±3times/min |
| Tapping height | 38±6mm |
| Levelness of the basement | ≤0.6mm/min |
| Rotation distance | 25 mm |
| Motor power | 0.37kW |
