Test Instrument

Home > Product > Environmental Test Chamber

Walk -in Environmental Temperature and Humidity Test Chamber

Guangdong Yuanyao Test Equipment Co., Ltd.
  • Certification：CE, TUV, ISO, SGS
  • Warranty：1 Year
  • Inner Size：3.6*2.7*2.4m
  • Temp. Range：-20 Degrees---70degrees
  • Humidity Range：30% Rh--90%Rh
  • Temp. Fluctuation：+,-0.3 Degree

Base Info

  • Model NO.：YWER-B2
  • Humi. Fluctuation：+,-2.5%Rh
  • Color：Ivory
  • Interior Chamber Material：SUS#304 Stainless Steel Plate
  • Exterior Chamber Material：Stainless Steel Plate + Powder Coated
  • Insulation System：PU&Fiberglass Wool
  • Wind Circulation System：Siroco Fan
  • Type：Material Testing Machine
  • Maxcapacity：<1000kn
  • Accuracy Grade：0.5
  • Load Way：Electronic Load
  • Loading Method：Static Load
  • Transport Package：Strong Plywood Case
  • Specification：SGS, TUV Certification
  • Trademark：Yuanyao
  • Origin：China
  • HS Code：9032100000
  • Production Capacity：10 Sets,Month

Description

ModelYWERInternal Dim.W×H×D(mm)Please refer to size chartExternal Dim.W×H×D(mm)Temperature Range 0ºC;-20ºC;-40ºC;-60ºC-- +70ºC(+80ºC)Humidity Range30--90%RHFerformanceTemp.&Humi,Constancy±0.3ºC;±2.5%RHTemp.&Humi,Constancy±0.1ºC;±5%RHIndication Resolution0.1ºC;0.1%RH/0.01;0.1%RHHeat-atºC80Timemin50Pull-downºC0-20-40Timemin5570100MaterialExteriorSUS#304 Stainless steel/PVC+Powder Coated InteriorUSU#304 stainless steel piateInsulationPloyurethane foam 100mm (75mm) (50mm)SystemsCirulationSiroco fanHeatingSUS#304 stainless steel high-speed heaterHumidifyingSurface evaporating system CoolingAirtight compressor+vaporator fins+air-cooling(or water-cooling)condenserDehumidifyingADP Critical dewpoint cooling/dehumidifying methodControllerDigital electronic indicators+S.S.R.With PIDOther ComponentsAirtight compressor+evaporator fins+air-cooling(or water-cooling)condenserSevey DevicesOverheating prevention ciruit-breaker, compressor overload protection,control system overload,humidifying systemoverheating & drying out prevention, breakdown indicator light.Power Source[K.W.]AC 1Ψ 220V;3Ψ 380V 60/50HzComply with ASTM D2436,JIS K7212,DIN 50011,BS 2648,IEC-540.More details about the specification, please contact Angela Cheng, thanks for your attention.

Except Customized size drive-in climate control test room, Dongguan Yuan Yao Electronics Technology Co., Ltd also can supply:

Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Automatic dispenser robot, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.

If you want to know more about the product, please feel free to contact us!
