• Model NO.：Stscj-300
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Oil Cylinder Position：Under
• Product Name：Testing Machine
• Max. Testing Power：300kn
• Measuring Range：12-300kn
• Indication Error：<1%
• Loading Precision：10n
• Loading Speed：100-5000n,S
• Lead Screw Stroke：100mm
• Max. Distance Between The Left and The R：850mm
• Power：AC220V±10% 1.0kw
• Transport Package：Export Standard Package
• Trademark：YuFeng
• Origin：Zhejiang, China
• HS Code：9031809090
• Production Capacity：30pieces,Month

Basic Info.

Model NO. Stscj-300 Control Computer Control Weight 100-500Kg Power Source AC220V Oil Cylinder Position Under Product Name Testing Machine Max. Testing Power 300kn Measuring Range 12-300kn Indication Error <1% Loading Precision 10n Loading Speed 100-5000n/S Lead Screw Stroke 100mm Max. Distance Between The Left and The R 850mm Power AC220V±10% 1.0kw Transport Package Export Standard Package Trademark YuFeng Origin Zhejiang, China HS Code 9031809090 Production Capacity 30pieces/Month

Product Description

Product Description
Features:
1. Relation curves between surplus testing power(or LESR) and the time are available.
2. Specimen Stress relaxation of 1000 hours could be calculated.
3. Loading speed 100-5000N/S, speed is variable.
4. Automatically calculate stress relaxation characteristic(such as stress relaxation rate)
and print complete testing report.
5. Load and displacement are calibrated by numbers.
6. Test results are saved and records of testing process could be consulted.
7. The system automatically adjusts coordinates under different testing condition.
Complete curve is indicated during test procedure.
8. Test parameters can be automatically saved, assigned out and re-set.
9. Data collection: You can use the mouse to collect data from the curve after the test
completed.
10. Stainless steel housing.
Technical parameters:
1.Max. testing power:300KN
2. Measuring range:12-300KN
3. Indication error:<1%
4. Loading precision:10N
5. Loading speed:100-5000N/S
6. Lead screw stroke:100mm
7. Max. distance between the left and the right clamps:850mm.
8. Power:AC220V±10% 1.0KW


Packaging & Shipping
Packing Material: Plywood Case meeting export long transport requirement.
Packing Method: Horizontal Packing to saving more shipping cost.
Shipping : within 5-10 days after receive 100% payment .
Shipping way: shipped by sea or Air is available.


Company Information
We are one of the  professional  manufacturing enterprises of geotechnical instruments, highway instruments and building material instruments in China. Our company's main products are divided into 13 series:
 1. Material Testing machines
 2. Soil Testing Equipment
 3. Cement Testing Equipment
 4. Concrete Testing Equipment
 5. Asphalt Testing Machines
 6. Rock Testing Equipment
 7. Aggregate
 8. Highway Testing Equipment
 9. Balances
 10. Moulds
 11. Sieves
 12. Lab Equipment
 13. Tools and Accessories for Lab
 14. Testing Equipments for drilling liquid mud

Our Services
Your inquiries will be replied in 24 hours, 24 hours technical support by email
Honesty to working for you, after or before  sale with our patient and sincerity.
If any products meet your demand, please feel free to contact us. We are sure your any inquiry or requirement will get prompt reply.

FAQ
1. Factory + trade (integration),35years focusing on test instruments field
2. We accept T/T, L/C or Western Union.
3. Generally about 15 days, If we have inventory, we can arrange shipment within 3 days. Please be aware that our production lead times depend on specific items and item quantities.
4.  For our products, we will give your professional guidance ( Product introduction  and operation  manual ). Air is available.
