IP5X~ IP6X Climatic Tester Dust Resistance Test Chamber
Guangdong Yuanyao Test Equipment Co., Ltd.- Max Diameter of Workpiece：1000mm
- Mass Scope of Workpiece：1000kg
- Type：Universal Testing Machine
- Maxcapacity：N,a
- Accuracy Grade：0.5
- Load Way：Electronic Load
Base Info
- Model NO.：YSDT-1000
- Loading Method：Dynamic Load
- Display：Digital
- Control：Controller
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：N,a
- Internal Size(mm)：1000*1000*1000
- Testing Type：IEC60529
- Testing Temp.：20 Degree Celsius +,- 15 Degree Celsius
- Concentration of Dust：Above5000 Mg , M3
- Humidity Range：45%Rh-85%Rh
- Swirl Time：No
- Material：Stainless Steel
- Warranty：12 Month
- Flow Rate of Dust：5m,S
- Total Time：2h
- Transport Package：Well Packed in Strong Plywood Cases.
- Specification：CE, ISO, SGS, TUV certified.
- Trademark：Yuanyao
- Origin：Guangdong, China
- HS Code：9032100000
- Production Capacity：100 Sets , Month
Description
ModelYSDT-1000-F YSDT-1000-C(IEC-529) Internal Dim.W×H×D(mm) 1000×1000×1000 1000×1000×1000 External Dim.W×H×D(mm) 1350×1950×1350 1350×1950×1350 Testing Type F1 F2 F3 IEC60529 C1 C2 Concentration of dust(mg/m3) Above 60000 Above 3000 Above 100 Above 5000 Above 100 Testing Temp. 20°C±15°C Huimidi.Range 45%RH~85%RH Flow rate of dust(m/s) No Limited 5m/s 10m/s Testing Time Swirl time 5S or other NO Rest time 15min or other Total time 5H 8H 8H 2H 6H Material Exterior SUS#304+Powder Coated Interior SUS#304 Other Components Chamber lamp,Wiper,Casters with adjusters Power Source(K.W.) AC 1Ψ 220V 60/50Hz 4KW
In addition to sand dust test equipment, we also produce:
1) Temperature/ humidity test series: Temperature humidity test chamber, Walk in environmental room, Thermal shock test chamber, High altitude low pressure simulation test chamber
2) Aging test series: Hot air oven, Vacuum drying oven, Air ventilation aging test chamber, Steam aging test chamber, Ozone resistance test chamber, Burn in test equipment
3) Weather simulation tes series: Rain spray test chamber, dust test chamber, Xenon lamp aging test chamber, UV test chamer
4) Mechanical test series: High frequency vibration test machine, drop test machine , Glue dispensing machine etc.
Customization service is available. If you have any better idea, please feel free to contact us!
Company profile
If you want to know more about dust test chamber,please feel free to contact us.
We are here waiting for you !
