• Model NO.：SS-8681
• Customized：Non-Customized
• Color：Yellow
• Basic Accuracy：±5%
• Meas. Speed：0.1 Sec Basic
• Test Signal Information：200~700VDC , 500VAC
• DC Insulation /Hi-Pot：±5% Accuracy
• Transport Package：Standard Wooden Case
• Specification：SanShine
• Trademark：SanShine
• Origin：China
• HS Code：9030899090
• Production Capacity：6000

Product Description

Display and Sound
 320×240 Graphic LCD Display
 6 Digits Numeral Formatting
 Pass/Fail LED Indicator/LCD Display
 Internal Speaker
 Connections
 128 Test Points
 256/512 Points Optional
 Hi-pot Calibration +/- Output
 Auto Pin-Search Jack
 Front Panel Buttons
 Sys Key/Fast Key/Edit Key/Soft Key
 I/O Interface
 Printer Port
 Remote Control Port (Optional)
 RS-232 Port (Optional)
 RS-485 Port (Optional)
 Memory
 Built-in 512KB SRAM
 Battery Backup
 Power Supply
 Switching 115/230 Vac±10%
 50/60Hz
 Accessory
 Auto Pin-Search Probe
 2-in-1 64Pin DIN-to-Horn Converter
 Remote Control Cable (Optional)
 RS-232 Cable (Optional)
 GPIB Cable (Optional)
 Power Cord
 3 → 2 Power Line Adapter
 User's Guide
 Temperature & Humidity
 15°C ~ 35°C
 RH ≤ 75%
 Dimension (WxHxD)
 425×190× 350mm
 Weight
 Approx, 14Kgs(w/o Accessory)
 Cable Capacitance Limit
 1μF Max.
 order code
 Description
 SS-8681N
 Cable/Harness Tester (DC 700V)
 SS-8681NC2
 256 Test Points
 SS-8681NC3
 512 Test Points
 SS-8681FA
 DC 700V , AC 500V Added
 SS-8681FAC2
 256 Test Points
 AV-8685DH1
 2-in-1 64Pin DIN-Horn Converter
 AK -8600F 1
 Fixture Flat Cable ( 30cm )
 KB-8685K1
 Calibration Fixture Set
