• Model NO.：GW-413
• Loading Method：Static Load
• Display：Digital
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC220V
• Transport Package：Wooden Case
• Specification：560*550*540mm(L*W*H)
• Trademark：Great Win
• Origin：Chian
• HS Code：9024800000
• Production Capacity：500 Sets,Year

Basic Info.

Model NO. GW-413 Loading Method Static Load Display Digital Control Manual Control Weight 0-100Kg Power Source AC220V Transport Package Wooden Case Specification 560*550*540mm(L*W*H) Trademark Great Win Origin Chian HS Code 9024800000 Production Capacity 500 Sets/Year

Product Description

Rubbing Fastness (Gakushin) Tester GW-413

Application:

Rubbing fastness (Gakushin) tester for JIS standards, for evaluating a material's resistance to rubbing motion. Unit is a six station, benchtop machine which includes clamps for sample attachment to moving platen and clams for weighted rubbing arm for attachment of rubbing material.
Cycle counter automatically stops machine at the end of test cycles. Test samples are visually evaluated. Includes two sets of test heads (6 heads each set) weighing 200g and 500g each, complete set of weights (6 each) of 100g, 300g, 400g and 800g which fit either test head. Each test arm is counterbalanced to offset arm weight. Suitable for dry and wet rubbing tests.
Specifications:

Work station:	6
pressure applied on rubbing finger:	2N
Travel length:	100 mm
Travel speed:	30 cpm
Specimen:	220 x 30mm
Counter:	1-999,999 times, automatically stops
Weight:	75kg
Power:	220/110V 50/60Hz 70W
Dimensions:	560*550*540mm(L*W*H)
Standards:	JIS 10801 JIS 0823 JIS 1084 TR 369B CNS 1499

FAQ:
What about the product quality?
For our products,each machine must be carried out 100% quality calibration and test when delivery goods.With CE certificate,we are very confident in our products,and we will pack them with safety wooden case to protect the machine when transport oversea .
What about usage of the machine?
we will also give your professional guidance(Product operating manual and video),each products comes with a USB flash drive which have all the details.
What about standards support?
We are strictly following different international standards such as EN,ISO,ASTM,AATC,JIS,GB ect,and had been recognized by SATRA,CSA international standard agency.
What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support,we can help them solve their problem through email,video meeting.We also can provide door to door service,but customer need to bear the travel fees.
