• Model NO.：HJ-69
• Display：Digital
• Control：Touch Screen Controller
• Weight：75kg
• Power Source：AC220V
• Oil Cylinder Position：No
• Counter：6 Bits (Built-in)
• Transport Package：Fumigation-Free Standard Export Wooden Box
• Trademark：Hongjin
• Origin：China
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. HJ-69 Display Digital Control Touch Screen Controller Weight 75kg Power Source AC220V Oil Cylinder Position No Counter 6 Bits (Built-in) Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ Month

Product Description

Product introduction:
1. The mobile phone touch screen scratch testing machine is a special equipment for scratch fatigue test on the mobile phone touch screen.
2. The structure design is reasonable and unique, and has full applicability to different types of mobile phones.
3. The equipment runs stably, with low noise and maintenance-free.
two. Testing purposes
1. Durability of the touchscreen.
2. Wear resistance of the touch screen.
3. Other functional checks.
three. Test procedure description
Simulate the operation of the touch screen with a stylus during the user's use.
The mobile phone is fixed in the horizontal (adjustable angle) fixture → the stylus is fixed in the fixture in the vertical direction to the touch screen (vertical floating, can be counterweight) → the motor drives the mobile phone fixture, and drives the mobile phone to move back and forth in a straight line → realize the stylus to swipe the touch screen injury test.
Four. Function realization
1. Servo motor realizes action; PLC control.
2. Large touch screen interface control.
3. Test distance, speed automatic input adjustment.


Number of workstations	2/unit.
Operation method	touch screen.
Action actuator	Panasonic Servo Motor.
Fixture angle range	0 to 90 degrees.
Reciprocating beat	10 to 60 times/min (automatic adjustment).
counter	6 bits (built-in).
Voltage	220V;
power	450W (including motor).
Dimensions	600x550x600
weight	75kg
