GDJB-1200A 6 phase secondary current injection test set

HV Hipot Electric Co., Ltd.
  • Type：Universal Testing Machine
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：38KG

Base Info

  • Model NO.：GDJB-1200A
  • Power Source：AC220V
  • Power Supply：AC 220V; 50Hz
  • 6-phase AC current output：(L-N) 6*0...30A
  • 3-phase AC current output：(L-N) 3*0...60A
  • 1-phase AC current output：(L-N) 1*0...180A
  • 6-phase DC current output：(L-N) 6*0...10A
  • 3-phase DC current output：(L-N) 3*0...20A
  • AC voltage output：(RMS) 0~120V
  • Size：460mm*340mm*640mm
  • Transport Package：Carton or Wooden Case
  • Specification：ISO, SGS
  • Trademark：HV Hipot
  • Origin：Wuhan China
  • HS Code：9030820000
  • Production Capacity：2000PCS,Year

Description

BinaryBinary input     10 channelsIdle contact      1~20mA, 24VPotential contact access  "0": 0 ~+6V; "1": +11 V ~+250 VBinary output     8 pairs   DC: 220 V/0.2 A; AC: 220 V/0.5 ATime Measuring Range0.1ms~9999s, Measuring accuracy: <0.1mSDimension & Weight480*360*200mm³, 19kg
