Plastic Auto-Print Izod Impact
Suzhou Qiantong Instrument Equipment Co., Ltd.- Max Diameter of Workpiece：4mm
- Mass Scope of Workpiece：<900kg
- Type：Impact Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
Base Info
- Model NO.：QT-5202 SERIES
- Loading Method：Dynamic Load
- Display：Digital
- Control：Manual Control
- Weight：40kg
- Power Source：AC220V
- Oil Cylinder Position：Electronic
- Transport Package：Wooden Case
- Specification：800× 350× 820mm
- Trademark：SUZHOU QIANTONG
- Origin：Jiangsu, China
- HS Code：9024800000
- Production Capacity：1000 Set,Year
Description
QT-5202 Izod Impact console 1set Qiantong screen 1set Wei Lun Tong Tai PLC 1 set German control system swing 1set Qiantong weight 1 pair Qiantong gradienter 1 piece Qiantong fixture jag 2 pieces (including the on on fixture mount) Qiantong middle sample plate 1 piece Qiantong power line 1 piece Qiantong Instruction book 1 piece Qiantong Quality certificate 1 piece Qiantong Inventory list 1 piece Qiantong
FAQ
Q:Are you a trade company or factory?
A:Our company is a factory and directly sales.
Q:Can your company accept customization?
A:Yes. Our machines can be customized by client.
Q:How to guarantee your after-sales service?
A:Our philosophy is one year warranty and lifetime service. After the warranty period is exceeded, if there is any problem, we will provide support for you in time. (only charge travel expense and parts cost at most.)
Q:What is the language about software?
A:It can switch between Chinese and English.
Q:May the customer not use your company's computer?
A:Sure. But please tell us what type your computer is. We need to confirm your computer can install the software. And we can subtract the price of computer from offer.
Q:Can the machine be upgrade?
A:Yes, it can.
| Name | Izod Impact |
| Impact speed | 3.5m/s |
| Swing energy | 5.5J |
| Swing angle | 150 |
| The distance between swing centre and impact blade point | 0.322m |
| Swing torque 5.5J swing PL=2.8355N.m | 5.5J swing PL=2.8355N.m 11J swing PL=5.671N.m 22J swing PL=11.3419N.m; |
| Distance from impact blade point to the top of fixture | 22mm |
| Blade corner radius | R=0.8mm |
| Specimen type | meets description of GB1843-80 and ISO1800-92 standard; |
| Power | 220V 50Hz 400W |
| Shape size | (L*W*H) 800×350×820mm |
