• Model NO.：KMH-150L
• Temp. Uniformity：+,-2.0oc
• Humidity Uniformity：+,-3.0%R.H.
• Heat up Time：-20oc~ +100oc Within 35mins
• Pull Down Time：+20 Oc~-20 Oc Within 45mins
• Equipment Power：7.5kw
• Martial：Stainless Steel
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and customs made
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets Per Year

Environmental Temperature and Humidity ChamberSecifications ( at +20ºC room temp.  Or+25ºC water temp with empty load)ModelKMH-L series64LTemp. range -40 ºC~+150ºCInterior sizelW(mm)400H(mm)400D(mm)400Exterior sizeW(mm)600H(mm)1526D(mm)1200Power(KW)4.5Weight(KG)150Humidity uniformity±3.0%R.HHeat up time -40ºC~+100ºC, within 45 minPull down time +20ºC~-40ºC , within 60 minStandard accessoriesSight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker, over pressureover heat and over current protection for compressor,Over temp. protect, over load protect of blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Single stage refrigeration system                      CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesHumidity Range20~98%R.HTemp. constancy±0.5ºC   Humidity constancy±2.5%R.HTemp. uniformity±2.0ºCInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolAmbient Temp.+5ºC~+35ºCWiring methodAC 380±10%50Hz ,3 phase 4 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
