ASTM D 1434 Plastic Film Sheeting Barrier Materials Gas Transmission Rate Test Machine
Pubtester Instruments Co., Ltd.- Test Method：Coulometric Sensor,Equal Pressure Method
- Standard：ASTM D3985
- Number of Specimens：3
- Permeable Area：50 Cm2
- Specimen Thickness：No More Than 3 mm
- Trademark：Pubtester
Base Info
- Model NO.：GTR-G3
- Origin：Shandong, Jinan
- HS Code：9027809990
- Production Capacity：10 Sets,Quarter
Description
Extended ApplicationClosure Systems Oxygen barrier property of various closure systems for bottles cartons and pouches Solar Back-Sheets Oxygen permeability test of solar back-sheets Plastic Tubes Oxygen permeability test of various sorts of tubes, e.g cosmetic tubes Blister Packs Test oxygen transmission rate of the whole blister packs Automotive and Small Engine Fuel Tanks Permeability of plastic fuel tanks Battery Plastic Shell Oxygen transmission rate of battery plastic shell
Technical Specifications
Standards
ASTM D3985, ASTM F2622, ASTM F1307, ASTM F1927, ISO 15105-2, DIN 53380-3, JIS K7126-B, YBB 00082003, GB/T 19789
Configuration
Standard configuration: Instrument, Vacuum grease, Sampler, Calibration film, Nitrogen/Oxygen pressure regulator
Optional configuration: Container test accessories, Container test temperature controller, Air Compressor
Note: Nitrogen and Oxygen are prepared by customer.
Are you a manufacturer or trading company?
We are the manufacturer and trading combo, which specialize in material testing instruments such as plastic package, medical device, facial mask, protective clothing and pharmaceutical package, etc. We located in Jinan, Shandong, China.
Do you have any certificate?
We have obtained CE certificate, passed ISO 9001, IPMS management system certificates, and have 18 utility model patents and 4 software copyright certificates.
How about the installation?
The user's manual specifies the installation requirements with details. We will advise the relative information in advance, such as power supply, space, required temperature, humidity, etc.
Do you have after-sales service?
We will carry out the equipment inspection before delivery. If the machine does not work properly, we can make a remote control service to help dealing with the failure. We promise to reply within 24 hours and provide solutions within 2 working days.
How about the warranty?
Our warranty is 12 month, lifelong free of charge! User just bear the materials cost and express charge out-of-warranty period.
How long does the delivery time?
For the regular machine, 3-5 working days. For the customized one, 30 days or so.
Technical Specifications
| Specifications | OTR-O3 |
| Test Range (film) | 0.01~6500 (cc/m2.24h) |
| Resolution | 0.001 |
| Permeable Area | 50 cm2 (Customizable) |
| Specimen Thickness | ≤3 mm |
| Number of Specimens | 3 |
| Number of Sensor | 3 |
| Test Mode | Three chambers independent |
| Temperature Control Range | 5ºC~95ºC (Temperature control device is optional) |
| Temperature Accuracy | ±0.1ºC |
| Carrier Gas | 99.999% High-purity Nitrogen (outside of supply scope) |
| Carrier Gas Flow | 0~100 mL/min |
| Carrier Gas Pressure | ≥0.2MPa |
| Port Size | 1/8inch metal tubing |
| Instrument Dimension | 740 mm (L) x 415 mm (W) x 430 mm (H) |
| Power Supply | AC 220V 50Hz |
| Net Weight | 50 kg |
Standards
ASTM D3985, ASTM F2622, ASTM F1307, ASTM F1927, ISO 15105-2, DIN 53380-3, JIS K7126-B, YBB 00082003, GB/T 19789
Configuration
Standard configuration: Instrument, Vacuum grease, Sampler, Calibration film, Nitrogen/Oxygen pressure regulator
Optional configuration: Container test accessories, Container test temperature controller, Air Compressor
Note: Nitrogen and Oxygen are prepared by customer.
